凯斯零件查询(LB434R XL) - BALER (11/16-) (55.100.040) - KNOTTER CLEANING FANS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
431 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84273529
|
[1] |
WIRE HARNESS
|
ZED
|
| 2. |
14496501
|
[12] |
WASHER,8.4mm ID x 17mm OD x 1.6mm Thk
|
TTF
Superseded by part number: 86624184
|
| 3. |
43127
|
[12] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
, Serial Range: -C136
|
| 3. |
43129
|
[12] |
BOLT,Hex, M8 x 1.25 x 40mm, LH Thd, Cl 8.8
|
NH
, Start Serial: D137 Superseded by part number: 16044024
|
| 4. |
9812123
|
[12] |
BUSHING,8.5mm ID x 16mm OD x 7mm L
|
ZED
|
| 5. |
84275427
|
[3] |
FAN
|
ZED
|
| 6. |
87556072
|
[12] |
NUT,Flng, 11.8mm OD x 19.8mm L
|
ZED
, Start Serial: D137
|
| 7. |
84391774
|
[1] |
SENSOR
|
ZED
, Start Serial: D162
|
| 8. |
47414530
|
[1] |
WIRE CONNECTOR
|
CUR
, Start Serial: D162
|
