凯斯零件查询(LB434R XL) - BALER (11/16-) (62.100.022) - PLUNGER, REAR - D160 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
530 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84100796
|
[4] |
ROLLER,72mm OD x 29mm L
|
ZED
|
| 2. |
47960197
|
[4] |
SUPPORT
|
ZED
|
| 3. |
84814847
|
[3] |
SHAFT
|
ZED
|
| 4. |
84814846
|
[1] |
SHAFT
|
ZED
|
| 5. |
47926078
|
[1] |
PLUNGER
|
ZED
|
| 5. |
47926076
|
[1] |
PLUNGER
|
ZED
|
| 5. |
47926074
|
[1] |
PLUNGER
|
ZED
|
| 5. |
47926071
|
[1] |
PLUNGER
|
ZED
|
| 6. |
84441749
|
[1] |
CAM
|
ZED
|
| 7. |
47470788
|
[2] |
BEARING
|
ZED
|
| 8. |
394632
|
[2] |
WASHER,21mm ID x 40mm OD x 4mm Thk
|
NH
|
| 9. |
1689
|
[2] |
NUT,3/4"-16, G5
|
NH
Superseded by part number: 80001689, 80001689, 87508272
|
| 10. |
9838305
|
[4] |
WASHER,26mm ID x 38mm OD x 2.27mm Thk
|
ZED
|
| 11. |
100033
|
[4] |
THIN NUT,Thin, M24 x 1.5, Cl 04
|
ZED
|
| 12. |
140046
|
[5] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 13. |
300388
|
[4] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 14. |
374895
|
[1] |
CARRIAGE BOLT,M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 15. |
543043
|
[1] |
WASHER,13mm ID x 35mm OD x 2.5mm Thk
|
NH
|
| 16. |
9706685
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
