凯斯零件查询(LB434R XL) - BALER (11/16-) (62.100.032) - PLUNGER, FRONT - D160 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1006 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47935606
|
[1] |
SCRAPER BLADE
|
ZED
|
| 2. |
47935252
|
[1] |
SCRAPER
|
ZED
|
| 3. |
47935052
|
[3] |
SCRAPER
|
ZED
|
| 3. |
47935063
|
[5] |
SCRAPER
|
ZED
|
| 4. |
84814869
|
[3] |
KNIFE,108mm L x 68mm W x 10mm Thk
|
ZED
|
| 4. |
84814868
|
[5] |
KNIFE,116mm L x 68mm W x 10mm Thk
|
ZED
|
| 5. |
84817042
|
[9] |
SHIM,45mm OD x 0.5mm Thk
|
ZED
|
| 6. |
84814870
|
[2] |
KNIFE,90mm L x 68mm W x 10mm Thk
|
ZED
|
| 7. |
84817044
|
[6] |
SHIM,45mm OD x 0.5mm Thk
|
CUR
|
| 8. |
47935256
|
[1] |
SCRAPER
|
ZED
|
| 9. |
47935617
|
[1] |
SCRAPER BLADE
|
ZED
|
| 10. |
47935233
|
[2] |
PLATE
|
ZED
|
| 11. |
380420
|
[10] |
BOLT
|
NH
|
| 12. |
140046
|
[31] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 13. |
9706685
|
[10] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 14. |
86592701
|
[21] |
WASHER,13mm ID x 35mm OD x 5mm Thk
|
ZED
|
| 15. |
300389
|
[14] |
BOLT,M12 x 1.75 x 35mm, Cl 8.8
|
NH
Superseded by part number: 628-12035
|
| 16. |
9628065
|
[7] |
SCREW,Hex, M12 x 1.75 x 45mm, Cl 8.8
|
NH
|
| 17. |
47935584
|
[1] |
SCRAPER BLADE
|
ZED
|
| 18. |
47935553
|
[1] |
SCRAPER
|
ZED
|
| 19. |
47935592
|
[1] |
SCRAPER BLADE
|
ZED
|
| 20. |
47935561
|
[1] |
SCRAPER
|
ZED
|
