神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (06-017) - LIGHT ASSY, ROTARY (FOR NORTH EUROPE) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
867 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1113F2 | [1] | LIGHT ASSY, ROTARY(FOR NORTH EUROPE) | |
| 1. | 2479R519 | [1] | LIGHT | KOB |
| 2. | 2416P7232 | [1] | SUPPORT | |
| 4. | ZS18C08016 | [5] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 5. | ZW26X08000 | [5] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 6. | 2418T10531 | [1] | PLATE | PLATE |
| 7. | ZS32T50008 | [4] | SCREW | KOBM05x08mm Self-Taper |
| 8. | 2479Z849 | [1] | SWITCH | KOB Superseded by part number: 2479Z514 |
| 9. | 2479Z851 | [1] | HARNESS | |
| 10. | 2479Z887 | [1] | HARNESS | HARNESS |
| 11. | 2479Z888 | [1] | HARNESS | |
| 12. | 2479Z869D4 | [1] | HARNESS | HARNESS |
| 13. | 2420Z1031 | [1] | GROMMET | KOBGROMMET |
| 14. | 2420Z1032 | [1] | GROMMET | KOBGROMMET |
| 15. | 2432Z290D3 | [5] | CLIP | KOBWire Ties -- 154mm Long, (NOT SHOWN) Superseded by part number: PY01P01043D3 |
| . . | 24100P1113F3 | [1] | LIGHT ASSY, ROTARY | |
| 16. | 2416P7279 | [1] | SUPPORT | |
