神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (06-018) - WASHER ASSY, WINDOW (FOR NORTH AMERICA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
927 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2965F1 | [1] | WASHER ASSY.WINDOW(FOR NORTH AMERICA) | |
| 1. | 24100U157F1 | [1] | TANK | KOB Superseded by part number: YT54C00003F1 |
| 2. | 2418Z633 | [1] | TUBE | KOB |
| 3. | 24100R43 | [1] | NOZZLE | KOB |
| 4. | 24100Z37 | [1] | NOZZLE | KOBADAPTER |
| 5. | 2479R702 | [1] | HARNESS, WIRING | HARNESS, WIRING |
| 6. | 2479U320 | [1] | SWITCH, WASHER | SWITCH, WASHER |
| 7. | ZS18C06016 | [2] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| 8. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 9. | 2432Z327 | [1] | PLATE | KOB |
| 10. | 2432Z309D1 | [3] | CLAMP | KOB |
