凯斯零件查询(LB434S) - BALER (9/12-) (35.540.030) - TENSION RAILS, HYDRAULIC LINES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
952 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84219028
|
[1] |
HYD TUBE
|
ZED
|
| 1. |
48014938
|
[1] |
HYD TUBE
|
ZED
|
| 2. |
84219030
|
[1] |
HYD TUBE
|
ZED
|
| 2. |
48014940
|
[1] |
HYD TUBE
|
ZED
|
| 3. |
84219024
|
[1] |
HYD TUBE
|
ZED
|
| 3. |
87364932
|
[1] |
|
HYD TUBE
|
| 4. |
84219026
|
[1] |
HYD TUBE
|
ZED
|
| 4. |
87364934
|
[1] |
HYD TUBE
|
ZED
|
| 5. |
84100140
|
[1] |
HYD CONNECTOR
|
ZED
|
| 6. |
9850318
|
[3] |
HYD CONNECTOR
|
ZED
|
| 7. |
379430
|
[1] |
3 WAY CONNECTION
|
ZED
|
| 8. |
84064562
|
[2] |
HYD CONNECTOR
|
ZED
|
| 9. |
84100885
|
[1] |
DRAINCOCK/TAP SUPPLY
|
ZED
|
| 10. |
84292365
|
[1] |
HYD TUBE
|
ZED
|
| 10. |
84292343
|
[1] |
HYD TUBE
|
ZED
|
| 11. |
84292367
|
[1] |
HYD TUBE
|
ZED
|
| 11. |
84292345
|
[1] |
HYD TUBE
|
ZED
|
| 11. |
87374135
|
[1] |
HYD TUBE
|
ZED
|
| 12. |
84418168
|
[1] |
HYD TUBE
|
ZED
|
| 12. |
84292369
|
[1] |
HYD TUBE
|
ZED
|
| 12. |
84292347
|
[1] |
HYD TUBE
|
ZED
|
| 13. |
335172
|
[1] |
HYD CONNECTOR,M14 x 1.5 x M14 x 1.5
|
ZED
|
| 14. |
84078517
|
[2] |
FLEXIBLE HOSE,6.35mm ID x 600mm L, SAE 100R1
|
ZED
|
| 15. |
84064567
|
[1] |
FLEXIBLE HOSE
|
ZED
|
| 16. |
396718
|
[2] |
STRAP
|
ZED
Superseded by part number: 529070
|
| 17. |
84295942
|
[1] |
HYDRAULIC HOSE,6.35mm ID x 705mm L, SAE 100R1
|
ZED
, Serial Range: -C084
|
| 17. |
84295944
|
[1] |
HYDRAULIC HOSE,6.35mm ID x 755mm L, SAE 100R1
|
ZED
, Start Serial: D085
|
| 19. |
430357
|
[16] |
CLAMP
|
DUB
|
| 20. |
434097
|
[3] |
SUPPORT
|
DUB
|
| 21. |
431941
|
[8] |
SUPPORT
|
DUB
|
| 22. |
412152
|
[5] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
| 23. |
397985
|
[3] |
BOLT,Hex, M6 x 70mm, Cl 8.8, Full Thd
|
NH
|
| 24. |
140015
|
[2] |
WASHER,6.4mm ID x 14mm OD x 1.6mm Thk
|
NH
Superseded by part number: 9820463
|
| 25. |
43118
|
[2] |
BOLT,Hex, M6 x 1.0 x 40mm, Cl 8.8
|
NH
Superseded by part number: 120102
|
| 26. |
87348037
|
[1] |
TUBE
|
ZED
, Start Serial: D024
|
| 27. |
87364975
|
[1] |
HYD TUBE
|
ZED
|
| 28. |
418283
|
[1] |
ELBOW
|
ZED
|
