| 1. |
84472261
|
[1] |
HYDRAULIC VALVE
|
ZED
Incl 2 - 5, Serial Range: -C084 Superseded by part number: 47517285
|
| 1. |
47517285
|
[1] |
HYDRAULIC MANIFOLD
|
ZED
Incl 2 - 5, 53, Serial Range: -F085136
|
| 1. |
84392323
|
[1] |
HYDRAULIC MANIFOLD
|
ZED
Incl 2 - 5, 53, Serial Range: -F137150
|
| 1. |
47971847
|
[1] |
HYDRAULIC MANIFOLD
|
ZED
Incl 2 - 5, 53, Start Serial: D151
|
| 2. |
87357750
|
[1] |
MAGNET
|
ZED
|
| 3. |
87357749
|
[1] |
HYDRAULIC VALVE
|
ZED
, Serial Range: -C084
|
| 3. |
47575437
|
[1] |
HYDRAULIC VALVE
|
ZED
, Serial Range: -F085150
|
| 3. |
47971849
|
[1] |
VALVE, PRESSURE CONT
|
ZED
, Start Serial: D151
|
| 4. |
47362462
|
[1] |
VALVE PRESSURE RELIE
|
ZED
, Serial Range: -C136
|
| 4. |
84392322
|
[1] |
VALVE PRESSURE RELIE
|
ZED
, Start Serial: D137
|
| 5. |
87357756
|
[1] |
HYDRAULIC VALVE
|
ZED
Incl 50 Superseded by part number: 247697A2
|
| 6. |
9706690
|
[5] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 7. |
84441294
|
[3] |
HYD CONNECTOR
|
ZED
|
| 8. |
335172
|
[2] |
HYD CONNECTOR,M14 x 1.5 x M14 x 1.5
|
ZED
|
| 9. |
84041508
|
[1] |
HYD CONNECTOR
|
ZED
, Serial Range: -C023
|
| 9. |
418283
|
[1] |
ELBOW
|
ZED
, Start Serial: D024
|
| 10. |
84287879
|
[1] |
HYD TUBE
|
ZED
, Serial Range: -C089
|
| 11. |
84287881
|
[1] |
HYD TUBE
|
ZED
, Serial Range: -C023
|
| 11. |
47384917
|
[1] |
HYD TUBE
|
ZED
, Start Serial: D024
|
| 12. |
84292351
|
[1] |
HYD TUBE
|
ZED
, Serial Range: -C023
|
| 12. |
47384919
|
[1] |
HYD TUBE
|
ZED
, Start Serial: D024
|
| 13. |
379430
|
[1] |
3 WAY CONNECTION
|
ZED
|
| 14. |
386215
|
[1] |
HYD CONNECTOR
|
ZED
|
| 15. |
395782
|
[1] |
HYD CONNECTOR,M18 x 1.5 ORB x M18 x 1.5 ORB
|
ZED
|
| 16. |
84219014
|
[1] |
HYD TUBE
|
ZED
|
| 17. |
84542417
|
[1] |
HYD TUBE
|
ZED
, Serial Range: -C023
|
| 17. |
47384915
|
[1] |
HYD TUBE
|
ZED
, Start Serial: D024
|
| 18. |
84542409
|
[1] |
HYD TUBE
|
ZED
, Serial Range: -C023
|
| 18. |
47384913
|
[1] |
HYD TUBE
|
ZED
, Start Serial: D024
|
| 19. |
412215
|
[2] |
BOLT,Hex, M8 x 1.25 x 100mm, Cl 8.8
|
NH
|
| 20. |
322358
|
[5] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 21. |
84405381
|
[1] |
RESERVOIR, HYDRAULIC
|
ZED
Incl 22 - 32
|
| 22. |
84405366
|
[1] |
RESERVOIR, HYDRAULIC
|
ZED
|
| 23. |
9508294
|
[1] |
FILLER CAP
|
ZED
Incl 24 - 26
|
| 24. |
87054105
|
[1] |
HYDRAULIC OIL FILTER
|
BEL
|
| 25. |
87054106
|
[1] |
FILLER CAP
|
BEL
|
| 26. |
87054107
|
[1] |
SEAL KIT
|
BEL
|
| 27. |
9824326
|
[6] |
WASHER,5.3mm ID x 10mm OD x 1mm Thk
|
NH
|
| 28. |
14304221
|
[6] |
HEX SOC SCREW,M5 x 16mm, Cl 8.8, Full Thd
|
LEC
Superseded by part number: 14304220
|
| 29. |
84071596
|
[1] |
PLASTIC PLUG,M31 x 19mm
|
ZED
|
| 30. |
417006
|
[1] |
PLUG
|
ZED
, Serial Range: -C055
|
| 30. |
150060
|
[1] |
PLUG
|
ZED
, Start Serial: D056
|
| 31. |
395019
|
[1] |
HYD CONNECTOR,M18 x 1.5 ORB x M16 x 1.5 ORB
|
PA
|
| 32. |
9516261
|
[1] |
HYD CONNECTOR
|
ZED
|
| 33. |
84025707
|
[1] |
HYD CONNECTOR
|
PLO
, Serial Range: -C091
|
| 33. |
87479525
|
[1] |
FITTING
|
PLO
, Start Serial: D092
|
| 34. |
84595967
|
[1] |
HYD TUBE
|
ZED
|
| 35. |
87716662
|
[2] |
NUT
|
ZED
|
| 36. |
430357
|
[8] |
CLAMP
|
DUB
|
| 37. |
431941
|
[4] |
SUPPORT
|
DUB
|
| 38. |
322357
|
[3] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 39. |
397985
|
[2] |
BOLT,Hex, M6 x 70mm, Cl 8.8, Full Thd
|
NH
|
| 40. |
43127
|
[3] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 41. |
84462240
|
[1] |
FLEXIBLE HOSE
|
ZED
|
| 42. |
396718
|
[1] |
STRAP
|
ZED
Superseded by part number: 529070
|
| 43. |
47357309
|
[1] |
SUPPORT
|
ZED
|
| 44. |
374891
|
[1] |
CARRIAGE BOLT,Rnd Head, M6 x 1 x 25mm, Cl 8.8
|
ZED
|
| 45. |
140015
|
[3] |
WASHER,6.4mm ID x 14mm OD x 1.6mm Thk
|
NH
Superseded by part number: 9820463
|
| 46. |
9706755
|
[1] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 47. |
120056
|
[2] |
BOLT,M6 x 1.0 x 54.15mm, Cl 8.8
|
NH
|
| 48. |
412152
|
[2] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
| 49. |
84605326
|
[1] |
HYDRAULIC HOSE,7.92mm ID x 320mm L, SAE 100R16
|
ZED
|
| 50. |
84418582
|
[1] |
SEAL KIT
|
ZED
|
| 51. |
87493874
|
[2] |
OPERATOR MANUAL RU
|
LIT
, Start Serial: D024
|
| 53. |
47517354
|
[1] |
SPRING
|
ZED
, Start Serial: D085
|
| 54. |
9511034
|
[1] |
SEAL
|
ZED
, Start Serial: D056 Superseded by part number: 722441
|
| 55. |
84218999
|
[1] |
HYDRAULIC HOSE
|
ZED
, Start Serial: D090
|
| 56. |
84219020
|
[1] |
HYD TUBE
|
ZED
, Start Serial: D090
|
| 57. |
47981046
|
[1] |
HYDRAULIC HOSE
|
ZED
|
