纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (07-012) - VALVE ASSY, CONTROL, (BOOM LOCK) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
392 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PM30V00048F1 | [1] | VALVE | KOBASSY, CONTROL |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONBODY |
| 2. | ZD12P01100 | [2] | O-RING | KOB |
| 3. | 2436U1317S13 | [1] | PLUG | KOB |
| 4. | PW30V01009S002 | [1] | POPPET | KOB |
| 5. | PH30V00014S013 | [1] | SPRING | KOB |
| 6. | PW30V01009S005 | [1] | PLUG | KOB |
| 7. | 2436R612S5 | [1] | O-RING | KOB |
| 8. | PW30V01011S015 | [1] | PLUG | KOB |
| 9. | ZD11P00600 | [1] | O-RING | KOB |
| 10. | PB30V00006S010 | [1] | O-RING | KOB |
| 11. | PR30V00007S014 | [1] | PLUG | KOB |
| 12. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 13. | PM22V00005F4 | [1] | PRESSURE RELIEF VALVE | KOBASSY, OVERLOAD, SEE FIG. 07-014 |
| . . | PW30V01026R100 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 14(1), 15(1), 16(1), 17(1), 18(1), 19(1), 20(1), 21(1), 22(2), 23(1), 24(1), 25(2), 26(1), 27(1), 28(1), 29(1), 30(1), 31(1), 32(1), 33(2) |
