| 1. |
89837395
|
[1] |
HANDLE
|
ZED
Superseded by part number: 9837395
|
| 2. |
84807440
|
[2] |
SUPPORT
|
ZED
|
| 3. |
84807437
|
[1] |
SHIELD
|
ZED
|
| 3. |
84807452
|
[1] |
SHIELD
|
ZED
|
| 4. |
84807456
|
[1] |
SUPPORT
|
ZED
|
| 4. |
84807454
|
[1] |
SUPPORT
|
ZED
|
| 5. |
80336455
|
[4] |
PLUG
|
ZED
Superseded by part number: 336455
|
| 6. |
84017837
|
[1] |
BRACKET
|
ZED
|
| 7. |
84000555
|
[2] |
INSULATOR,Bumper
|
ZED
|
| 8. |
84015292
|
[1] |
LATCH
|
ZED
Latch, 1/4 Turn
|
| 9. |
84037127
|
[1] |
SUPPORT
|
ZED
|
| 9. |
89837422
|
[1] |
ANGLE BAR
|
ZED
Superseded by part number: 9837422
|
| 10. |
84607903
|
[1] |
GUARD
|
ZED
|
| 10. |
84607902
|
[1] |
GUARD
|
ZED
Superseded by part number: 84819358
|
| 11. |
84100274
|
[2] |
HINGE
|
ZED
|
| 12. |
84607901
|
[1] |
SHIELD
|
ZED
|
| 12. |
84607900
|
[1] |
PLATE
|
ZED
|
| 13. |
84607897
|
[1] |
PLATE
|
ZED
|
| 14. |
84607896
|
[1] |
PLATE
|
ZED
|
| 15. |
84078201
|
[2] |
BRACKET
|
ZED
|
| 16. |
89837397
|
[2] |
GAS STRUT
|
ZED
Superseded by part number: 9837397
|
| 17. |
84607899
|
[1] |
SHIELD
|
ZED
|
| 17. |
84607998
|
[1] |
|
REINFORCEMENT
|
| 18. |
80043442
|
[2] |
NUT,M8 x 1.25, Cl 8
|
ZED
Superseded by part number: 82034883
|
| 19. |
84100271
|
[2] |
HINGE
|
ZED
|
| 20. |
80140045
|
[2] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 21. |
89839580
|
[2] |
SCREW,Hex Soc Hd, M8 x 70, 8.8
|
ZED
M8x70
|
| 22. |
811-6016
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 16mm, Cl 8.8
|
CAS
Superseded by part number: 86512439
|
| 23. |
80322357
|
[1] |
LOCK WASHER,Belleville, M6
|
ZED
6MM Superseded by part number: 322357
|
| 25. |
120104
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 26. |
80140016
|
[4] |
WASHER
|
ZED
8MM Superseded by part number: 86624184
|
| 27. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 28. |
614-6016
|
[6] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86508568
|
| 30. |
811-8020
|
[22] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 31. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 29. |
89706690
|
[1] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 32. |
89837417
|
[4] |
BALL JOINT
|
ZED
Superseded by part number: 9837417
|
| 33. |
84100868
|
[2] |
BRACKET
|
ZED
|
| 34. |
84807438
|
[1] |
SHEET
|
ZED
LH
|
| 35. |
84807439
|
[1] |
PLATE
|
ZED
RH
|
| 36. |
80120041
|
[2] |
CARRIAGE BOLT
|
ZED
Superseded by part number: 120041
|
| 24. |
15896221
|
[1] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
