| 1. |
84074102
|
[1] |
PLATE
|
ZED
, Serial Range: -C305
|
| 1. |
84818514
|
[1] |
PLATE
|
ZED
, Start Serial: D306
|
| 1. |
84074104
|
[1] |
PLATE
|
ZED
, Serial Range: -C305
|
| 1. |
84818512
|
[1] |
PLATE
|
ZED
, Start Serial: D306
|
| 2. |
80067510
|
[1] |
SHIM
|
ZED
Superseded by part number: 86622604
|
| 3. |
84806230
|
[1] |
DOOR
|
ZED
|
| 3. |
84806228
|
[1] |
DOOR
|
ZED
|
| 3. |
84607925
|
[1] |
DOOR
|
ZED
|
| 4. |
84100073
|
[2] |
SHOCK ABSORBER
|
ZED
|
| 5. |
84100271
|
[1] |
HINGE
|
ZED
|
| 6. |
84015292
|
[1] |
LATCH
|
ZED
Latch, 1/4 Turn
|
| 7. |
84100274
|
[1] |
HINGE
|
ZED
|
| 8. |
84806229
|
[1] |
SHIELD
|
ZED
|
| 8. |
84806227
|
[1] |
SHIELD
|
ZED
|
| 8. |
84607926
|
[1] |
SHIELD
|
ZED
|
| 9. |
84017837
|
[1] |
BRACKET
|
ZED
|
| 10. |
80401266
|
[1] |
STRIP-GASKET
|
ZED
Superseded by part number: 401266
|
| 11. |
85001637
|
[1] |
FOOT BOARD
|
ZED
|
| 11. |
85001617
|
[1] |
FOOT BOARD
|
ZED
|
| 11. |
84400114
|
[1] |
FOOT BOARD
|
ZED
|
| 12. |
80336455
|
[4] |
PLUG
|
ZED
Superseded by part number: 336455
|
| 13. |
84000418
|
[1] |
PLATE
|
ZED
(29)
|
| 13. |
89837272
|
[1] |
PROFILE
|
ZED
(29) Superseded by part number: 9837272
|
| 13. |
84429662
|
[1] |
PROFILE
|
ZED
|
| 14. |
80624592
|
[1] |
ANTI-SKID STRIP
|
ZED
550x18MM Superseded by part number: 624592
|
| 15. |
80043154
|
[2] |
BOLT
|
ZED
M12x40 Superseded by part number: 86629541
|
| 16. |
86511324
|
[2] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
Superseded by part number: 87364
|
| 17. |
80100038
|
[2] |
NUT
|
ZED
M12 Superseded by part number: 100038
|
| 18. |
80338949
|
[6] |
CARRIAGE BOLT
|
ZED
M10x25 Superseded by part number: 338949
|
| 19. |
80140045
|
[14] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 20. |
100016
|
[15] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 21. |
811-8020
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 22. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 24. |
120104
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 25. |
89839580
|
[1] |
SCREW,Hex Soc Hd, M8 x 70, 8.8
|
ZED
M8x70
|
| 26. |
80043442
|
[1] |
NUT,M8 x 1.25, Cl 8
|
ZED
Superseded by part number: 82034883
|
| 27. |
811-10030
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 28. |
80120041
|
[4] |
CARRIAGE BOLT
|
ZED
M10x20 Superseded by part number: 120041
|
| 29. |
89837273
|
[1] |
SCRAPER BLADE
|
ZED
Superseded by part number: 84800478
|
| 23. |
89706690
|
[1] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 30. |
89837395
|
[1] |
HANDLE
|
ZED
Superseded by part number: 9837395
|
| 31. |
614-6016
|
[2] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86508568
|
| 32. |
80322357
|
[2] |
LOCK WASHER,Belleville, M6
|
ZED
6MM Superseded by part number: 322357
|
| 33. |
15896221
|
[2] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
