纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (07-033) - CYLINDER ASSY, ARM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
862 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PX01V00063F1 | [1] | CYLINDER | KOBCYLINDER ASSY, ARM Superseded by part number: PX01V00063F2 |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONTUBE, CYLINDER |
| 2. | PW01V01086D1 | [2] | BUSHING | KOB |
| 4. | PW01V00068S004 | [1] | CYLINDER END CAP | KOBCYLINDER HEAD |
| 5. | PV01V00047S019 | [1] | BUSHING | KOBBUSHING |
| 6. | 2438U635S3 | [1] | RING | KOB |
| 7. | PH01V00006S006 | [1] | RING | KOB |
| 8. | ZD12G07500 | [1] | O-RING,74.40mm ID x 80.60mm OD x 3.10mm | KOB |
| 9. | PH01V00015S008 | [1] | BACK-UP RING | KOB |
| 10. | ZD12G08000 | [1] | O-RING,79.40mm ID x 85.60mm OD x 3.10mm | KOB |
| 11. | PX01V00042S011 | [1] | PISTON | KOB |
| 12. | 2438U852S15 | [1] | RING | KOB |
| 13. | PW01V00068S018 | [2] | RING | KOBRING, SLIDE |
| 14. | 2438U1057S16 | [1] | SET SCREW | KOB |
| 15. | 2436U946S11 | [1] | BALL | KOB |
| 16. | PX01V00048S016 | [1] | CUSHION | KOB |
| 17. | YT01V00002S023 | [1] | SEAL | KOB |
| 18. | 2438U1116S24 | [2] | STOP | KOB |
| 19. | 2438U1116S23 | [1] | RING | KOB |
| 20. | PR01V00002S027 | [4] | SEAL | KOB |
| 21. | ZG91U02000 | [2] | LUBE NIPPLE | KOB |
| . . | PX01V00063R100 | [1] | REPAIR KIT | KOBREPAIR KIT, CONSISTS OF REF. 1(1), 2(1), 20(2) |
| . . | PX01V00048R200 | [1] | ROD | KOBCONSISTS OF REF. 2(1), 3(1), 20(2) |
| . . | PX01V00042R300 | [1] | SEAL | KOBCONSISTS OF REF. 6(1), 7(1), 8(1), 9(1), 10(1), 12(1), 13(2) |
