神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (01-014) - TANK ASSY, FUEL, P/N 24100J1836F5 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
658 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J1836F5 | [1] | TANK ASSY. FUEL CONSISTS OF REF. 4 TO 36 | |
| 4. | 2418T4055 | [1] | FLANGE | |
| 5. | 2427U127F1 | [1] | SENDER UNIT | KOB |
| 6. | 2436R241F1 | [1] | COCK | KOBINCL. REF. 6-2 Superseded by part number: LC20P01028P1 |
| 6-2. | B41N0094E14 | [1] | PACKING | |
| 7. | ZD11G16500 | [1] | O-RING,164.30mm ID x 175.70mm OD x 5.70mm | KOBID 164.30 ± 1.30 x OD 175.7mm |
| 8. | ZD11G08500 | [1] | O-RING,84.40mm ID x 90.60mm OD x 3.10mm | KOBID 84.40 ± 0.61 x OD 90mm |
| 10. | ZS11C10025 | [10] | CAP,Hex, M10 x 25mm, Cl 4.8 | KOBScrew -- M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 12. | ZS12C16040 | [6] | SCREW,Hex, M16 x 40mm | KOBM16x2.0x40mm |
| 14. | ZW11X16000 | [6] | WASHER | KOBID 16 x OD 30 x Th 2.3mm |
| 15. | ZW22X10000 | [10] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 16. | ZW22X16000 | [6] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 17. | R36T0006 | [1] | STRAINER ELEMENT | KOB |
| 18. | W14P0020E4 | [1] | PACKING | KOB |
| 32. | W14P0020E2 | [1] | CAP | KOB |
| 33. | ZE72T16000 | [1] | PLUG | KOB |
| 34. | ZE72T06000 | [2] | PLUG | PLUG |
| 35. | ZE91T02000 | [2] | PLUG | |
| 36. | 2427J1105 | [1] | TANK, FUEL | |
