纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (07-038) - VALVE ASSY, PILOT (PROPELLING) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
549 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PM30V00019F4 | [1] | PILOT VALVE | KOBASSY, (PROPELLING) Incl 101 - 501 |
| 101. | NSS | [1] | NOT SERVICED SEPARATELY | CONCASE |
| 202. | PM30V00019S202 | [4] | PLUG | KOB |
| 203. | PM30V00019S203 | [4] | CAP | KOB |
| 210. | PM30V00019S210 | [4] | PACKING | KOB |
| 211. | PM30V00019S211 | [4] | O-RING | KOB |
| 212. | YT30V00009S212 | [4] | O-RING | KOB |
| 213. | ZD12P00800 | [2] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 218. | PM30V00019S218 | [4] | SPRING SEAT | KOB |
| 225. | 2436U625S232 | [12] | BALL | KOB |
| 251. | YW30V00001S157 | [3] | PLUG | KOB |
| 252. | 2441U722S490 | [2] | PLUG | KOB1/16" NPTF |
| 261. | ZD12P01100 | [3] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 271. | PM30V00019S271 | [4] | CAPSCREW | KOBSCREW |
| 324. | PM30V00019S324 | [4] | SPRING | KOB Superseded by part number: PM30V00019S012 |
| 335. | PM30V00019S335 | [4] | SPRING | KOB |
| 336. | PM30V00019S336 | [4] | SPRING | KOB |
| 414. | EN30V00045S414 | [4] | BUSHING | KOBBUSHING |
| 501. | PM30V00019S501 | [2] | BOOT | KOB |
| . . | PM30V00019R100 | [1] | REPAIR KIT | KOBBOOT, CONSISTS OF REF. 210(4), 211(4), 212(4), 213(2) |
| . . | PM30V00019R300 | [1] | REPAIR KIT | KOBBOOT, REPAIR KIT, CONSISTS OF REF. 413(1), 420(1), 472(1), 471(2) |
