纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (07-039) - VALVE ASSY, PILOT (PROPELLING), P/N PB30V00002F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
144 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PB30V00002F1 | [1] | PILOT VALVE | KOBASSY, (PROPELLING) Superseded by part number: PB30V00002F2 |
| 101. | NSS | [1] | NOT SERVICED SEPARATELY | CONCASE |
| 202. | PB30V00002S202 | [2] | PLUG | KOB |
| 210. | PM30V00019S210 | [2] | PACKING | KOB |
| 212. | 2436U2946S9 | [2] | O-RING | KOB Superseded by part number: YX30V00009S162 |
| 251. | YW30V00001S157 | [1] | PLUG | KOB |
| 261. | ZD12P01100 | [1] | O-RING | KOB |
| 271. | ZS23C06016 | [2] | SCREW,Hex Socket Head, M6 x 16mm | KOBCAP Superseded by part number: ZS28C06016 |
| 472. | EN30V00024S472 | [1] | SCREW | KOBSET |
