纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (03-011[01]) - BOOM CYLINDER INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
229 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT02B00085F1 | [1] | Boom | |
| 1. | YT02B00086F1 | [1] | | |
| 2. | YT02B01138P1 | [1] | PIN | KOB |
| 3. | YR02B01298P1 | [1] | PIN | KOB |
| 4. | HS18C12125G2 | [1] | SCREW | KOBCap |
| 5. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBCap |
| 6. | 2418T21137 | [1] | WASHER | KOB |
| 7. | ZW16H10000 | [1] | WASHER | KOB |
| 8. | ZN18C12010 | [2] | NUT | KOB |
| 9. | YT02B01008D1 | [1] | SHIM | KOB(0.5) |
| 10. | B16T0442D93 | [1] | SHIM,120mm OD x 72mm ID x 0.9mm Thk | KOB(0.9) |
| 11. | YT02B01008D2 | [1] | SHIM | KOB(1.2) |
| 12. | YR02B01262P1 | [2] | SHIM | KOB(2.0) |
| 13. | B16T0442D82 | [1] | SHIM,120mm OD x 77mm ID x 0.5mm Thk | KOB(0.5) |
| 14. | B16T0442D81 | [1] | SHIM,120mm OD x 77mm ID x 0.9mm Thk | KOB(0.9) |
| 15. | B16T0442D80 | [1] | SHIM,120mm OD x 77mm ID x 1.2mm Thk | KOB(1.2) |
| 16. | YR02B01261P1 | [2] | SHIM,2mm Thk | KOB(2.0) |
| 17. | YT01V00034F1 | [1] | LIFT CYLINDER | KOBBoom |
