神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (11-016) - AIR LINES INSTAL, UPP, G.M. ENG. MOUNT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
577 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X891F1 | [1] | INSTAL,UPP AIR LINES CONSISTS OF REF. 1 TO 93 | |
| 1. | R38N0012 | [1] | RESERVOIR | KOB |
| 2. | ZG22B08006 | [2] | CONNECTOR | CONNECTOR |
| 3. | ZH22Z06000 | [2] | CONNECTION | KOB |
| 4. | R38N0014 | [1] | KIT DIA, CRAWLER EXC | KOB |
| 5. | B90P0027F1 | [1] | VALVE | KOBCONSISTS OF REF. 5-1 TO 5-6 |
| 5-1. | R38N0008 | [1] | VALVE | KOB |
| 5-2. | B06P0037 | [1] | LEVER | KOB |
| 5-3. | R25P0032D1 | [1] | ROLLER SHAFT | KOB |
| 5-4. | ZP26D06020 | [1] | PIN | KOBRoll -- OD 06 x 20mm Long |
| 5-5. | ZS11C06025 | [1] | CAPSCREW M06x1.0x25mm | CAPSCREW M06x1.0x25mm |
| 5-6. | ZN11C06005 | [1] | NUT | KOBNUT M06x1.0mm Superseded by part number: ZN18C06005 |
| 6. | R38T0014 | [4] | VALVE | KOB |
| 7. | 2446U155F3 | [1] | VALVE, REDUCTION INCL. REF. 7-21 TO 7-30 | VALVE, REDUCTION INCL. REF. 7-21 TO 7-30 |
| 7-21. | 2446U133S21 | [1] | AIR FILTER | KOB |
| 7-22. | 2446U133S22 | [1] | O-RING | KOB |
| 7-30. | 2446U155S30 | [1] | BOWL | BOWL |
| 8. | R38N0013 | [1] | HORN, AIR | HORN, AIR |
| 9. | R38T0001D4 | [1] | VALVE PRESSURE RELIE | KOB |
| 10. | B20T0041 | [2] | U-BOLT | KOB |
| 11. | ZX22M06130 | [2] | HOSE | KOB1300mm Long (51-3/16 in) |
| 12. | 2418P3715 | [2] | TUBE | TUBE |
| 13. | 2418N901 | [1] | TUBE | |
| 14. | 2444T1342 | [2] | HYD CONNECTOR | KOB |
| 15. | ZX15K08500 | [1] | TUBE, NYLON | TUBE, NYLON |
| 16. | ZX15K08300 | [3] | FLEXIBLE HOSE | KOB |
| 17. | ZX15K04350 | [2] | TUBE, NYLON | TUBE, NYLON |
| 18. | ZX15K08200 | [1] | TUBE | KOB |
| 19. | ZX15K08100 | [1] | TUBE | KOB |
| 20. | R44P0034 | [2] | CONNECTOR | CONNECTOR |
| 22. | ZX15K06400 | [1] | TUBE | KOB |
| 23. | ZX15K08400 | [1] | TUBE | KOB |
| 24. | W18P0077 | [2] | ADAPTER | ADAPTER |
| 25. | R45P0030 | [2] | PACKING | PACKING |
| 26. | ZX15K04200 | [3] | TUBE | KOB |
| 27. | 20Z646D22 | [4] | CAPSCREW | CAPSCREW |
| 29. | R27T0016 | [1] | HINGE | KOB |
| 31. | 2444Z1624D3 | [1] | HOSE | HOSE |
| 34. | R44P0043D2 | [3] | HYD CONNECTOR | KOB |
| 35. | ZG21E06004 | [7] | CONNECTOR | CONNECTOR |
| 36. | ZG21B06004 | [4] | HYD CONNECTOR | KOB |
| 37. | ZG21E04000 | [6] | HYD CONNECTOR | KOB |
| 38. | ZG21U04000 | [2] | SOCKET | KOB |
| 39. | ZG22E02000 | [1] | HYD CONNECTOR | KOB1/8"-1/8"PT x 26mm Long |
| 41. | ZH21K04004 | [1] | HYD CONNECTOR | KOB |
| 42. | ZH21K08004 | [2] | HYD CONNECTOR | KOB |
| 43. | R44P0046D3 | [3] | ELBOW | KOB |
| 44. | ZH31K08006 | [2] | ELBOW | KOB |
| 45. | ZH31K08004 | [4] | ELBOW | KOB |
| 46. | ZH31K06006 | [1] | ELBOW | ELBOW |
| 47. | ZH31K06004 | [1] | ELBOW | KOB |
| 48. | ZH31K04004 | [9] | ELBOW | KOB |
| 49. | ZG31U06000 | [2] | TEE | |
| 51. | ZG51U06000 | [2] | TEE | KOB |
| 52. | ZG51U04000 | [3] | TEE | KOB |
| 55. | R44T0102D1 | [1] | CROSS | CROSS |
| 56. | R38T0002 | [2] | COCK, DRAIN | COCK, DRAIN |
| 57. | 2444Z1695D4 | [1] | HYD CONNECTOR | KOB |
| 60. | ZS11C10016 | [2] | CAPSCREW M10x1.50x16mm | CAPSCREW M10x1.50x16mm |
| 61. | ZS11C08020 | [2] | SCREW,Hex, M8 x 20mm, Cl 4.8 | KOBCAPTIVE WASHER SCREW CAPSCREW Superseded by part number: ZS18C08020 |
| 62. | ZS11C08012 | [7] | SCREW,Hex, M8 x 12mm, Cl 4.8 | KOBM08x1.25x12mm Superseded by part number: ZS18C08012 |
| 63. | ZS11C06030 | [2] | CAPSCREW | |
| 64. | ZS11C06025 | [2] | CAPSCREW M06x1.0x25mm | CAPSCREW M06x1.0x25mm |
| 66. | ZW22X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 67. | ZW22X08000 | [13] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 68. | ZW22X06000 | [6] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 70. | ZW11X10000 | [6] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
| 71. | ZW11X08000 | [2] | WASHER | KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000 |
| 72. | ZN11C08007 | [14] | NUT | KOBM08x1.25mm Superseded by part number: ZN16C08007 |
| 74. | ZX15K04550 | [1] | TUBE, NYLON | |
| 76. | ZC15X01500 | [4] | CLIP | KOB |
| 78. | R16P0036D1 | [7] | CLAMP | KOB Superseded by part number: ZC46X12011 |
| 80. | R16T0063D3 | [1] | GROMMET | KOB |
| 81. | R16T0063D4 | [1] | GROMMET | KOBGROMMET |
| 82. | R16T0063D5 | [1] | | |
| 83. | ZG21U06000 | [3] | HYD CONNECTOR | KOB |
| 84. | ZH21K08006 | [3] | HYD CONNECTOR | KOB |
| 85. | ZH51K08006 | [2] | TEE | KOB |
| 86. | R16T0124 | [5] | BLOCK TAPPED | |
| 87. | 2418N1131 | [1] | TUBE | TUBE |
| 88. | ZH51K04004 | [1] | TEE | |
| 89. | ZH31K04002 | [2] | ELBOW | KOB |
| 90. | ZS11C06012 | [2] | SCREW,Hex, M6 x 12mm, Cl 4.8 | KOBM06x1.0x12mm Superseded by part number: ZS18C06012 |
| 91. | 2416P3905 | [1] | BLOCK | |
| 92. | ZS11C10014 | [2] | CAPSCREW M10x1.50x14mm | CAPSCREW M10x1.50x14mm |
| 93. | ZE72T04000 | [2] | PLUG | KOB |
