神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (11-017) - POWER-PLANT INSTAL, G.M. ENG. MOUNT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
986 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J1423F5 | [1] | HEATER. INST CONSISTS OF REF. 1 TO 15 | |
| 1. | R79N0007 | [1] | HEATER | KOB |
| 3. | R16T0238D1 | [4] | CLIP | KOB |
| 4. | R16T0239 | [2] | GROMMET | GROMMET |
| 1. | 2432Z186D1 | [5] | CLIP | CLIP |
| 8. | 2432Z187 | [5] | RING, CLIP | RING, CLIP |
| 9. | 2416Z53 | [1] | BRACKET | |
| 10. | ZS11C10016 | [4] | CAPSCREW M10x1.50x16mm | CAPSCREW M10x1.50x16mm |
| 11. | ZW22X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 12. | R38T0016 | [2] | COCK | KOB |
| 13. | ZG21B08006 | [2] | BUSHING | KOB |
| 15. | R18T0026D26 | [2] | HOSE | HOSE |
