| . . | 24100X892F1 | [1] | INSTAL, POWER-PLANT CONSISTS OF REF. 1 TO 101 | |
| . . | 24100X892F2 | [1] | INSTAL, POWER-PLANT CONSISTS OF REF. 1 TO 101 | |
| 1. | 2451U176F1 | [1] | ENGINE | |
| 2. | 2441U210F2 | [1] | PUMP | PUMP |
| 3. | 2441R6F2 | [1] | PUMP | KOB |
| 4. | 2418R176F1 | [1] | COUPLING | KOB |
| 5. | 2418P5292 | [1] | COUPLING | COUPLING |
| 6. | 2418P5293 | [1] | FLANGE | KOB |
| 7. | 2427U171 | [1] | MUFFLER | |
| 8. | 2452U173F1 | [1] | RADIATOR | |
| 9. | 2418T6578 | [1] | PLATE | PLATE |
| 10. | 2416R138 | [8] | RUBBER PAD | KOB |
| 11. | ZS13C18100 | [4] | SCREW | KOBM18x2.0x100mm |
| 12. | 2418T6295 | [4] | PLATE | KOB |
| 13. | ZN13C18015 | [4] | NUT | KOBM18x2.5mm |
| 14. | 2416P4780 | [2] | BRACKET BRACKET | |
| 15. | 2416N1876D1 | [1] | BRACKET | |
| 16. | 915987 | [12] | EXCHANGE ENGINE | BERCAPSCREW |
| 17. | ZW22X14000 | [20] | LOCK WASHER | KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000 |
| 18. | ZS13C12100 | [8] | SCREW | KOB Superseded by part number: ZS18C12100 |
| 19. | 2416P4980 | [2] | BLOCK | |
| 20. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 21. | 2418N914 | [1] | PIPE | KOB |
| 22. | 2418P3783 | [1] | PIPE | PIPE |
| 23. | R18T0001D1 | [1] | HOSE | KOB |
| 24. | ZC15X12500 | [4] | CLIP | KOB |
| 25. | ZC15X08000 | [4] | CLIP | KOB |
| 26. | 2444Z1697D1 | [1] | HOSE | KOB |
| 27. | ZS12C12040 | [5] | CAPSCREW M12x1.75x40mm | CAPSCREW M12x1.75x40mm |
| 28. | ZD11G05000 | [1] | O-RING,3.1mm Thk x 49.4mm ID, 70 Duro | KOBO-Ring -- ID 49.40 ± 0.45 x OD 55mm |
| 29. | ZW22X12000 | [37] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 30. | ZS12C16040 | [4] | SCREW,Hex, M16 x 40mm | KOBM16x2.0x40mm |
| 31. | ZW22X16000 | [10] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 32. | ZD11G11000 | [1] | O-RING,109.40mm ID x 115.60mm OD x 3.10mm | KOBID 109.40 ± 0.91 x OD 115mm |
| 33. | 2416N1876D2 | [1] | BRACKET | |
| 34. | 2427P1525 | [1] | PIPE, TAIL | PIPE, TAIL |
| 35. | 2420T3485 | [2] | U-BOLT | |
| 36. | 2416P4784 | [2] | BRACKET | |
| 37. | 2432T1281 | [1] | CLAMP | CLAMP |
| 38. | 2418P5937 | [1] | PIPE | |
| 39. | 2432Z307F1 | [1] | CLAMP | CLAMP |
| 40. | 2416T6345 | [2] | STAY | |
| 41. | 2416T6840 | [2] | BRACKET | |
| 42. | 2416P4770 | [2] | BRACKET | |
| 43. | ZS12C16060 | [8] | SCREW,Hex, M16 x 60mm | KOBM16x2.0x60mm |
| 44. | ZN12C16013 | [14] | NUT | KOBM16x2.0mm |
| 45. | 2416T4036 | [8] | WASHER | |
| 46. | ZS12C16045 | [4] | SCREW,Hex, M16 x 45mm | KOBM16x2.0x45mm Superseded by part number: ZS13C16045 |
| 47. | 2418P5936 | [1] | PIPE | PIPE |
| 48. | 2418P5934 | [1] | PIPE | PIPE |
| 49. | 2444Z1859D1 | [1] | HOSE | HOSE |
| 50. | 2418P5943 | [1] | PIPE | PIPE |
| 51. | 2416T6344 | [1] | BRACKET | |
| 52. | 2418P5819 | [1] | COUPLING | COUPLING |
| 53. | 0626V037 | [1] | CAPSCREW,FOR F1 ONLY | |
| 54. | 2427P1485 | [1] | DUCT | |
| 55. | 2427P1484D1 | [1] | DUCT DUCT | |
| 56. | 2427P1484D2 | [1] | DUCT | |
| 57. | 2427P1400 | [1] | DUCT | |
| 58. | 2418P5308 | [1] | PIPE | PIPE |
| 59. | 2420P1231 | [1] | HOSE | HOSE |
| 60. | 2418P5307 | [1] | PIPE | PIPE |
| 61. | R38T0016 | [1] | COCK | KOB |
| 62. | 2420P1230 | [1] | HOSE | KOB |
| 63. | ZS23C20050 | [8] | SCREW,Hex Socket Head, M20 x 50mm | KOBM20x2.5x50mm |
| 64. | ZP26D08016 | [8] | ROLL PIN | KOB |
| 65. | ZS73C20035 | [2] | SETSCREW | |
| 66. | ZS23C10030 | [8] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm Superseded by part number: ZS28C10030 |
| 67. | ZW22K10000 | [8] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 68. | ZC15X06000 | [4] | CLIP | KOB |
| 69. | ZS11F12030 | [4] | CAPSCREW | |
| 70. | 2446U163S1 | [1] | AIR CLEANER INCL. REF.70-1 TO 70-2 | |
| 70-1. | 2446U163S12 | [1] | ELEMENT, INNER | ELEMENT, INNER |
| 70-2. | 2446U163S13 | [1] | ELEMENT, AIR CLEANER | ELEMENT, AIR CLEANER |
| 71. | ZS11F10016 | [16] | CAPSCREW | |
| 72. | 2416N1767 | [1] | BRACKET | BRACKET |
| 73. | R45P0022 | [1] | PACKING | PACKING |
| 74. | 2414N1185 | [1] | HOUSING | |
| 75. | 2432Z163D6 | [6] | CLAMP ASSY | CLAMP ASSY |
| 76. | ZS12C12025 | [8] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 77. | ZS11C10030 | [6] | CAPSCREW,Hex, M10 x 30mm, Cl 4.8 | KOBSCREW M10x1.50x30mm |
| 78. | ZN12C12010 | [5] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 79. | ZS12C16110 | [2] | CAPSCREW M16x2.0x110mm | CAPSCREW M16x2.0x110mm |
| 80. | ZN11C10008 | [8] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 81. | ZS11C06012 | [2] | SCREW,Hex, M6 x 12mm, Cl 4.8 | KOBM06x1.0x12mm Superseded by part number: ZS18C06012 |
| 82. | ZW22X10000 | [34] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 83. | 916313 | [8] | CAPSCREW CAPSCREW | |
| 84. | 0609V054 | [12] | CAPSCREW | |
| 85. | 0628V065 | [12] | CAPSCREW | |
| 86. | ZW22K12000 | [12] | LOCK WASHER | KOBID 12.2 x OD 17.8 x Th 2.5mm |
| 87. | 2418T6290 | [4] | WASHER | |
| 88. | ZW22X06000 | [2] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 89. | ZX23M04070 | [1] | HOSE ASSY. | KOB700mm Long (27-1/2 in) |
| 90. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 91. | 2418P5912 | [1] | PIPE,FOR F2 ONLY | |
| 92. | 2418P5935 | [1] | PIPE,FOR F1ONLY | |
| 93. | 2432T1282 | [1] | CLAMP,FOR F1ONLY | |
| 94. | 2416T7007 | [1] | BRACKET,FOR F1ONLY | |
| 95. | 2444Z195D1 | [1] | ADAPTER | ADAPTER |
| 96. | 2H32Z04000 | [1] | CONNECTOR | |
| 97. | 2446U128S3 | [1] | AIR PRE-CLEANER ASSY | KOBPRE-CLEANER ASSY |
| 98. | 2446U163S2 | [1] | REDUCER | |
| 99. | 2444Z1600D5 | [2] | ELBOW | KOB |
| 100. | R51P0005 | [1] | INDICATOR | INDICATOR |
| 101. | R16P0061 | [2] | BAND | BAND |
| . . | 5108989 | [1] | CONTROL SHAFT | MKTGASKET(GM ENGINE PART) Superseded by part number: 5123255 |
