神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (11-023) - LABEL NAME-PLATE (G.M. ENG. MOUNT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
296 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J2449F3 | [1] | LABEL,NAME-PLATE CONSISTS OF REF. 1 TO 30 | |
| 1. | 2432J690 | [2] | LABEL | KOB |
| 2. | 2432T1530 | [1] | IDENTITY PLATE | KOB |
| 6. | 2432N749 | [1] | NAME-PLATE | NAME-PLATE |
| 8. | 2432T865 | [1] | LABEL | |
| 12. | 2420Z64 | [2] | RIVET | RIVET |
| 19. | 2432P523 | [1] | PLATE | PLATE |
| 21. | 2432T885 | [2] | PLATE | PLATE |
| 23. | 2432T892 | [1] | LABEL | KOB |
| 24. | 2432T1016 | [1] | PLATE, CAUTION | |
| 25. | 2432T1017 | [1] | LABEL | LABEL |
| 26. | 2432N801 | [1] | CHART, LUB | CHART, LUB |
| 27. | 2432T1215 | [1] | DATA PLAQUE | KOBDecal, Caution - To prevent accidents and bodily injury … |
| 26. | 2432T959 | [1] | LABEL | KOB |
| 29. | 2432T1231 | [2] | DATA PLAQUE | KOBDecal, Warning - |
| 30. | 2432N578 | [1] | PLATE | KOB |
