凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (01.09[01]) - FLYWHEEL, SLIP CLUTCH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1011 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84043383
|
[1] |
CLUTCH
|
ZED
, Serial Range: (2-19)
|
| 2. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 3. |
84045923
|
[1] |
PRESSURE RING
|
ZED
|
| 4. |
84026570
|
[2] |
RING
|
ZED
|
| 5. |
84026569
|
[1] |
CIRCLIP
|
ZED
|
| 6. |
84043391
|
[1] |
DISC
|
ZED
|
| 7. |
84043390
|
[1] |
DISC
|
ZED
|
| 8. |
84043389
|
[4] |
BRAKE LINING
|
ZED
LINING, BRAKE
|
| 9. |
84036393
|
[1] |
BUSHING
|
ZED
|
| 10. |
84043388
|
[1] |
YOKE
|
ZED
|
| 11. |
84036391
|
[1] |
SHAFT
|
ZED
|
| 12. |
84026576
|
[1] |
CLUTCH INPUT SHAFT
|
ZED
|
| 13. |
84043395
|
[1] |
HOUSING
|
ZED
|
| 14. |
84043394
|
[1] |
RING
|
ZED
|
| 15. |
84043393
|
[1] |
DISC
|
ZED
|
| 16. |
84036392
|
[1] |
PIN
|
ZED
|
| 17. |
84043387
|
[8] |
NUT
|
ZED
|
| 18. |
84004301
|
[1] |
REPAIR KIT
|
ZED
|
| 19. |
84437788
|
[1] |
CIRCLIP
|
ZED
|
