| 1. |
84074482
|
[1] |
CAP
|
ZED
, Serial Range: -C305
|
| 2. |
80370026
|
[2] |
CIRCLIP
|
ZED
, Serial Range: -C305 Superseded by part number: S301572
|
| 3. |
84074466
|
[2] |
CIRCLIP
|
ZED
, Serial Range: -C305
|
| 4. |
84074475
|
[2] |
BEARING ASSY
|
ZED
, Serial Range: -C305 Superseded by part number: 9516384
|
| 5. |
80300919
|
[2] |
LUBE NIPPLE,M8 x 1
|
ZED
, Serial Range: -C305 Superseded by part number: 84447449
|
| 6. |
84074452
|
[2] |
HUB
|
ZED
, Serial Range: -C305 Superseded by part number: 84587348
|
| 7. |
84074472
|
[2] |
SHIM,85.3mm ID x 99.8mm OD x 1mm Thk
|
ZED
, Serial Range: -C305
|
| 8. |
80300904
|
[2] |
RING
|
ZED
, Serial Range: -C305 Superseded by part number: 84817177
|
| 9. |
84074484
|
[1] |
ARM
|
ZED
, Serial Range: -C305 Superseded by part number: 84800771
|
| 9. |
84819397
|
[1] |
ARM
|
ZED
, Start Serial: D306 Superseded by part number: 84800771
|
| 10. |
84074462
|
[2] |
BOLT,Hex, M24 x 140mm, Cl 10.9
|
ZED
M24x150, Serial Range: -C305
|
| 10. |
84819389
|
[2] |
BOLT,M27 x 150mm
|
ZED
M27x150, Start Serial: D306 Superseded by part number: 84800770
|
| 11. |
84074425
|
[2] |
WASHER
|
ZED
24MM, Serial Range: -C305
|
| 11. |
84819390
|
[2] |
WASHER
|
ZED
27MM, Start Serial: D306
|
| 12. |
84074479
|
[1] |
SEALING RING
|
ZED
SEALRING, Serial Range: -C305
|
| 13. |
84074485
|
[1] |
ARM
|
ZED
, Serial Range: -C305 Superseded by part number: 84800772
|
| 13. |
84819398
|
[1] |
ARM
|
ZED
, Start Serial: D306 Superseded by part number: 84800772
|
| 14. |
84819395
|
[1] |
ARM
|
ZED
(1 to 11), Start Serial: D306 Superseded by part number: 84800773
|
| 15. |
84819396
|
[1] |
ARM
|
ZED
(2 to 8, 10 to 13), Start Serial: D306 Superseded by part number: 84800774
|
