| 1. |
84078017
|
[1] |
SUPPORTING ARM
|
ZED
LH
|
| 1. |
84078011
|
[1] |
SUPPORTING ARM
|
ZED
RH
|
| 2. |
80921928
|
[4] |
RING
|
ZED
Superseded by part number: 921928
|
| 3. |
80378248
|
[2] |
WASHER
|
ZED
25MM Superseded by part number: 378248
|
| 4. |
80435967
|
[2] |
SPRING
|
ZED
Superseded by part number: 435967
|
| 5. |
89503523
|
[2] |
PIN
|
ZED
Superseded by part number: 412660
|
| 6. |
84022829
|
[2] |
PIN
|
ZED
Superseded by part number: 412689
|
| 7. |
89814947
|
[2] |
SUPPORT
|
ZED
Superseded by part number: 9814947
|
| 8. |
89839002
|
[6] |
EXTERNAL REFLECTOR
|
ZED
Superseded by part number: 9839002
|
| 9. |
84073095
|
[2] |
WIRE HARNESS
|
ZED
|
| 10. |
80449531
|
[2] |
LAMP
|
ZED
Superseded by part number: 449531
|
| 11. |
80353078
|
[2] |
BULB
|
ZED
Superseded by part number: 3050199R91
|
| 12. |
80336483
|
[2] |
LAMP, TAIL
|
ZED
LIGHT, TAIL White Superseded by part number: 336483
|
| 13. |
80470016
|
[2] |
BULB
|
ZED
Superseded by part number: E35556
|
| 14. |
84072549
|
[1] |
WIRE HARNESS
|
ZED
, Serial Range: -C341 Superseded by part number: 84072224
|
| 14. |
84075307
|
[1] |
WIRE HARNESS
|
ZED
, Serial Range: -C341 Superseded by part number: 84075286
|
| 14. |
84072224
|
[1] |
WIRE HARNESS
|
ZED
, Serial Range: -C341
|
| 14. |
84075286
|
[1] |
WIRE HARNESS
|
ZED
, Serial Range: -C341
|
| 15. |
80398224
|
[1] |
POWER SOCKET
|
ZED
Superseded by part number: 83959716
|
| 16. |
84005685
|
[4] |
STRIP-GASKET
|
ZED
|
| 17. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Rivet
|
| 18. |
80746294
|
[4] |
LAMP REFLECTOR
|
ZED
|
| 19. |
80322356
|
[1] |
WASHER
|
ZED
Superseded by part number: 322356
|
| 20. |
263117
|
[1] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
CABLE STRAP
|
| 21. |
84037090
|
[2] |
TAIL LAMP,12V, 21W, Amber/Red
|
ZED
, Serial Range: (22-25)
|
| 23. |
80398877
|
[2] |
BULB
|
ZED
12V-21W Superseded by part number: 14148190
|
| 24. |
80418870
|
[2] |
BULB
|
ZED
12V-5W Superseded by part number: 14149590
|
| 26. |
84076074
|
[1] |
WIRE HARNESS
|
ZED
|
| 27. |
84100424
|
[1] |
SUPPORT
|
ZED
|
| 27. |
84320762
|
[1] |
PLATE
|
ZED
|
| 28. |
80445502
|
[1] |
LAMP
|
ZED
Superseded by part number: 445502
|
| 29. |
80470017
|
[1] |
BULB
|
ZED
Superseded by part number: 10863090
|
| 30. |
80385682
|
[2] |
BOLT
|
ZED
M4x30 Superseded by part number: 385682
|
| 31. |
80322355
|
[2] |
WASHER
|
ZED
4MM Superseded by part number: 322355
|
| 32. |
80100012
|
[2] |
NUT
|
ZED
M4 Superseded by part number: 57121
|
| 33. |
NS
|
[1] |
NOT SERVICED
|
BAS
Cable, Harness
|
| 34. |
80799266
|
[1] |
LAMP REFLECTOR
|
ZED
White Superseded by part number: 799266
|
| 35. |
86547710
|
[1] |
EMBLEM
|
ZED
KIT SMV
|
| 36. |
84100426
|
[1] |
PLATE
|
ZED
|
| 37. |
80043139
|
[1] |
BOLT,M10 x 25mm
|
ZED
M6x20 Superseded by part number: 11106231
|
| 38. |
80412649
|
[1] |
LOCK WASHER
|
ZED
6MM Superseded by part number: 412649
|
| 39. |
15896221
|
[1] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
