凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (06.03[01]) - REVOLVING FLASH LIGHT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
638 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
89513421
|
[1] |
BEACON
|
ZED
Superseded by part number: 9513421
|
| 2. |
89513422
|
[1] |
WIRE CONNECTOR
|
ZED
Superseded by part number: 9513422
|
| 3. |
84073655
|
[1] |
SUPPORT
|
ZED
|
| 4. |
84073092
|
[1] |
WIRE HARNESS
|
ZED
|
| 5. |
84074631
|
[1] |
CONTACT HOUSING,Female, 2 Pole
|
ZED
Superseded by part number: 87695582
|
| 6. |
80043129
|
[2] |
SCREW
|
ZED
M8x40 Superseded by part number: 16044024
|
| 7. |
80322358
|
[2] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 9. |
84000651
|
[1] |
RELAY
|
ZED
Superseded by part number: 86529089
|
| 10. |
84100298
|
[1] |
FUSE
|
ZED
10A Superseded by part number: 9811773
|
| 8. |
89706690
|
[2] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
