凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (06.05[01]) - WORK LIGHTS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
688 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84004176
|
[1] |
WORK LAMP
|
ZED
, Serial Range: (2-5,7,8,10,11,16) Superseded by part number: 84790030
|
| 2. |
89837140
|
[1] |
LAMP
|
ZED
(3,16) Superseded by part number: 9837140
|
| 3. |
80417720
|
[1] |
BULB
|
ZED
12V-55W Superseded by part number:
|
| 4. |
120104
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 5. |
80378243
|
[2] |
WASHER
|
ZED
Superseded by part number: 378243
|
| 6. |
89813909
|
[1] |
SUPPORT
|
ZED
Superseded by part number: 9813909
|
| 7. |
80322358
|
[2] |
LOCK WASHER
|
ZED
Superseded by part number: 322358
|
| 9. |
89837606
|
[1] |
CLIP
|
ZED
Superseded by part number: 847590
|
| 10. |
80264517
|
[1] |
WIRE HARNESS
|
ZED
Superseded by part number: 264517
|
| 11. |
80353969
|
[1] |
ELEC CONNECTOR
|
ZED
Superseded by part number: 86508819
|
| 12. |
80374418
|
[1] |
POWER SOCKET
|
ZED
Connector, Serial Range: -C257 Superseded by part number: 374418
|
| 12. |
82002966
|
[1] |
POWER SOCKET
|
IMO
, Start Serial: D258 Superseded by part number: 84191453
|
| 13. |
89819611
|
[1] |
LAMP
|
ZED
Superseded by part number: 9819611
|
| 14. |
84000651
|
[1] |
RELAY
|
ZED
Superseded by part number: 86529089
|
| 15. |
84100299
|
[1] |
FUSE,25A, Micro, Clear
|
ZED
25A
|
| 16. |
84814248
|
[1] |
SWITCH
|
ZED
|
| 8. |
89706690
|
[2] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
