凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (06.04[01]) - SIDE LIGHTS, DENMARK Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
577 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84073089
|
[2] |
WIRE HARNESS
|
ZED
|
| 2. |
84058158
|
[6] |
SIDE LAMP ASSY
|
ZED
|
| 3. |
80100012
|
[12] |
NUT
|
ZED
M4 Superseded by part number: 57121
|
| 4. |
80322355
|
[12] |
WASHER
|
ZED
4MM Superseded by part number: 322355
|
| 5. |
86511042
|
[12] |
SCREW,Pan Head, M4 x 0.7 x 16mm, Cl 4.8
|
ZED
Superseded by part number: 13272214
|
| 6. |
84058228
|
[6] |
BULB,12V, 5W
|
ZED
12V-4W
|
