凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (06.59[01]) - CONNECTORS, 6 PIN: X200 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
529 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84074643
|
[1] |
CONTACT HOUSING,Female, 6 Pole
|
ZED
|
| 2. |
84074641
|
[1] |
WEDGE
|
ZED
Superseded by part number: 87694150
|
| 3. |
80900364
|
[1] |
TERMINAL CONNECTOR
|
A
female, for #16 AWG wire Superseded by part number: 900364
|
| 3. |
80900569
|
[1] |
TERMINAL
|
ZED
female, for #14 AWG wire Superseded by part number: 87695618
|
| 4. |
84074642
|
[1] |
WIRE CONNECTOR,Male
|
ZED
|
| 5. |
89861378
|
[1] |
ELEC. TERMINAL PIN
|
ZED
Superseded by part number: 87694147
|
| 6. |
80900363
|
[1] |
TERMINAL
|
ZED
male, for #16 AWG wire Superseded by part number: 87695607
|
| 6. |
80900552
|
[1] |
TERMINAL
|
ZED
male, for #14 AWG wire Superseded by part number: 87695915
|
| 7. |
84058832
|
[1] |
CLIP
|
ZED
see 06.56
|
| 8. |
84068583
|
[1] |
PLUG,12 - 16 Ga, White
|
ZED
Superseded by part number: 87695652
|
