| . . | 24100J2299F3 | [1] | ARM ASSY, CONSISTS OF REF 1 TO 58 | |
| 1. | 2411X524F1 | [1] | ARM , CONSISTS OF REF 1-1 TO 1-34 | |
| 1 -1. | 2411X524 | [1] | ARM | |
| 1-29. | 2405T702 | [4] | BUSHING | KOB |
| 1-30. | 2405T703 | [2] | BUSHING | KOB |
| 1-31. | 2418T5647D1 | [2] | SPACER | KOB |
| 1-34. | 2418T6152 | [1] | SPACER | KOB |
| 2. | 2406J114F1 | [2] | LINK | KOBCONSISTS OF REF 2-7 & 2-8 |
| 2-7. | 2405T700 | [1] | BUSHING | BUSHING |
| 2- 8. | 2405T701 | [1] | BUSHING | BUSHING |
| 3. | 2406J116F1 | [1] | LINK, BUCKET, CONSISTS OF REF 3-7 TO 3-9 | |
| 3-7. | 2405T698 | [2] | BUSHING | BUSHING |
| 3-8. | 2405T702 | [2] | BUSHING | KOB |
| 3-9. | 44Z1D10 | [2] | FITTING | KOB |
| 6. | 2419P946 | [3] | PIN | PIN |
| 7. | 2419P945 | [1] | PIN | PIN |
| e. | 2419P1034 | [2] | PIN | PIN |
| 9. | 2418P4454 | [1] | TUBE | KOB |
| 10. | 2418T5558 | [1] | TUBE | TUBE |
| 12. | 2432T995 | [8] | CLAMP | KOB |
| 13. | R16P0035D3 | [2] | CLAMP | KOB |
| 14. | B16T0006 | [2] | PLATE | PLATE |
| 16. | R16P0036D17 | [5] | CLAMP | CLAMP |
| 17. | ZX58N16160 | [2] | FLEXIBLE HOSE | KOB1600mm Long (63 in) |
| IS. | 2420R349D250 | [2] | HOSE,2500.00 mm | KOB |
| 20. | 2420R349D340 | [1] | HOSE | KOB3400mm Long (133-55/64 in) Superseded by part number: HX21E04340DX |
| 21. | 2420R349D230 | [1] | HOSE ASSY. | KOB2300mm Long (90-1/2 in) |
| 22. | R44P0034 | [2] | CONNECTOR | CONNECTOR |
| 23. | ZH32Z04000 | [2] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 24. | ZH22Z04000 | [6] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 25. | 2420T2747D7 | [6] | SHIM,112mm ID x 180mm OD x 1.2mm Thk | KOBID 112 x OD 180 x Th 1.2mm |
| 26. | 2420T2747D8 | [6] | SHIM,112mm ID x 180mm OD x 1.6mm Thk | KOBID 112 x OD 180 x Th 1.6mm |
| 27. | 2420T2747D9 | [6] | SHIM,112mm ID x 180mm OD x 2.3mm Thk | KOBID 112 x OD 180 x Th 2.3mm |
| 28. | 2420T2747D10 | [6] | SHIM,112mm ID x 180mm OD x 3.2mm Thk | KOBID 112 x OD 180 x Th 3.2mm |
| 29. | 2418T5224D1 | [2] | SHIM | KOB |
| 30. | 2418T5224D2 | [2] | SHIM | KOB |
| 31. | 2418T5224D3 | [2] | SHIM | KOB |
| 32. | 2418T5224D4 | [2] | SHIM | KOB |
| 33. | 2420T2747D2 | [2] | SHIM,102mm ID x 170mm OD x 1.2mm Thk | KOBID 102 x OD 170 x Th 1.2mm |
| 34. | 2420T2747D3 | [2] | SHIM,102mm ID x 170mm OD x 1.6mm Thk | KOBID 102 x OD 170 x Th 1.6mm |
| 35. | 2420T2747D4 | [2] | SHIM,102mm ID x 170mm OD x 2.3mm Thk | KOBID 102 x OD 170 x Th 2.3mm |
| 36. | 2420T2747D5 | [2] | SHIM,102mm ID x 170mm OD x 3.2mm Thk | KOBID 102 x OD 170 x Th 3.2mm |
| 38. | ZS11C12120 | [16] | CAPSCREW M12x1.75x120mm | CAPSCREW M12x1.75x120mm |
| 39. | ZS12C16080 | [4] | CAPSCREW M16x2.0x80mm | CAPSCREW M16x2.0x80mm |
| 40. | ZS12C12030 | [4] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm Superseded by part number: ZS18C12030 |
| 41. | ZS12C08012 | [7] | CAPSCREW M08x1.25x12mm | CAPSCREW M08x1.25x12mm |
| 42. | ZS23C14075 | [4] | CAPSCREW,Hex Socket Head, M14 x 75mm | KOBSCREW M14x2.0x75mm |
| 43. | ZN11C12010 | [32] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 44. | ZS23C14035 | [4] | SCREW,Hex Socket Head, M14 x 35mm | KOBM14x2.0x35mm |
| 45. | ZW22X16000 | [4] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 46. | ZW22X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 47. | ZW22X08000 | [7] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 48. | ZW22K14000 | [8] | LOCK WASHER | KOBID 14.2 x OD 21.8 x Th 3.5mm |
| 49. | ZD12P03800 | [2] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 50. | 44Z1D10 | [13] | FITTING | KOB |
| 51. | ZN11C16013 | [4] | NUT | KOBM16x2.0mm |
| 52. | R16T0227D3 | [2] | SPACER | KOB |
| 53. | 2418T5364 | [2] | SPACER | KOB |
| 54. | ZG32B04000 | [2] | ELBOW | KOB |
| 55. | 2432P572D2 | [1] | CLAMP | |
| 57. | 2438U498F2 | [1] | CYLINDER | CYLINDER |
| 58. | 44Z226D1 | [1] | PLUG | |
