凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (06.63[01]) - CONNECTORS: X3 - X4 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
199 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84074252
|
[1] |
TERMINAL CONNECTOR,Male
|
ZED
|
| 2. |
80636664
|
[1] |
CLAMP
|
ZED
Superseded by part number: 636664
|
| 3. |
80900363
|
[1] |
TERMINAL
|
ZED
male Superseded by part number: 87695607
|
| 4. |
84068583
|
[1] |
PLUG,12 - 16 Ga, White
|
ZED
Superseded by part number: 87695652
|
| 5. |
84074251
|
[1] |
ELEC CONNECTOR
|
ZED
|
| 6. |
80636665
|
[1] |
LOCK WASHER
|
ZED
Superseded by part number: 84607513
|
| 7. |
80636666
|
[1] |
NUT
|
ZED
Superseded by part number: 459329C1
|
| 8. |
80900364
|
[1] |
TERMINAL CONNECTOR
|
A
female Superseded by part number: 900364
|
