凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (06.64[01]) - CONNECTORS, TRACTOR BATTERY HOOK-UP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
717 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
80444852
|
[1] |
TERMINAL
|
ZED
10MM for 16-20MM² Superseded by part number: 444852
|
| 2. |
80335101
|
[1] |
TERMINAL
|
ZED
10MM for 4-6MM²
|
| 3. |
80335483
|
[1] |
ELEC CONNECTOR
|
ZED
6MM for 4-6MM²
|
| 4. |
80335316
|
[1] |
TERMINAL
|
A
6MM for 0.3-1.3MM² Superseded by part number: 335316
|
| 5. |
84078783
|
[1] |
FUSE,80A, Midival
|
ZED
80A
|
| 6. |
84078784
|
[1] |
FUSE HOLDER
|
ZED
|
