神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (09-025) - MITSUBISHI 6D20C ENGINE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
427 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA3093293300 | [2] | MUFFLER | |
| 2. | VA1226653100 | [2] | CLAMP | KOB |
| 3. | NSS | [2] | NOT SOLD SEPARAT | CONTAIL PIPE |
| 4. | VA3093293200 | [4] | SCREW | KOBU-BOLT |
| 5. | NSS | [2] | NOT SOLD SEPARAT | CONCLAMP |
| 6. | NSS | [2] | NOT SOLD SEPARAT | CONEXHAUST PIPE |
| 7. | VA3003090051 | [2] | AIR CLEANER ASSY | AIR CLEANER ASSY |
| 8A. | VA3113016400 | [2] | AIR CLEANER | KOBELEMENT (OUTER) |
| 8B. | VA3003083100 | [2] | AIR FILTER | KOB(INNER) |
| 9. | VA3003070200 | [2] | AIR PRE-CLEANER ASSY | KOB |
| 10. | VA3113016200 | [4] | BAND | BAND |
| 11. | VA3113017700 | [2] | ELBOW | KOBRUBBER |
| 12. | VA3123011850 | [4] | HOSE CLAMP | KOB |
| 13. | VA3093094400 | [1] | RUBBER HOSE | |
| 14. | VA3093094500 | [1] | RUBBER HOSE | |
| 15. | VA0303606600 | [2] | PIPE VINYL HOSE | PIPE VINYL HOSE |
| 16. | VAMS666005 | [6] | CLIP | CLIP |
| 17. | VAME900743 | [2] | BELT, TRANSMISSION | KOB(WATER PUMP) Superseded by part number: N13884 |
| 18. | VAME902958 | [2] | BELT | KOB(FAN DRIVE) |
| 19. | VA3091490900 | [2] | RUBBER SLEEVE | KOBCUSHION |
| 20. | VA3091491100 | [4] | RUBBER CUSHION | |
| 21. | VA3001453200 | [16] | SEAT | KOBRUBBER |
| 22. | VA3094601600 | [2] | RUBBER HOSE | |
| 23. | VAMF661026 | [4] | CLAMP | |
| 24. | VA3094792500 | [2] | ELBOW | KOBRUBBER Superseded by part number: VAME440664 |
| 25. | VAMS666021 | [4] | CLAMP | |
| 26. | VA3094790300 | [2] | HOSE | KOBRUBBER |
| 27. | VAMH020008 | [8] | CLIP | KOB Superseded by part number: VAMH020388 |
| 28. | NSS | [2] | NOT SOLD SEPARAT | CONRUBBER HOSE |
| 29. | VA3097508200 | [1] | SUCTION PIPE | KOBRUBBER ELBOW |
| 30. | VAMS66601 | [2] | CLAMP | |
| 31. | VAME971150 | [1] | FUEL FILTER | |
| 32. | VA3006265101 | [1] | FUELPILTE ELEMENT | |
| 33. | VA3124053015 | [1] | OIL FILTER | |
| 34. | VA3124053103 | [1] | OIL FILTE ELEMENT | |
| 35. | VA3124053103 | [1] | OIL FILTE ELEMENT | |
| 37. | VAMC822841 | [2] | AIR PRESSURE GOVERNOR | |
| 38. | VAMH035107 | [8] | GASKET | KOB Superseded by part number: VAMH035195 |
| 39. | VA3189091600 | [2] | THERMO SWITCH | |
| 40. | VAMC840219 | [2] | SWITCH | KOBOIL PRESSURE Superseded by part number: H411892 |
| 41. | VA3089080401 | [2] | GAUGE | KOBTHERMO SENDING UNIT Superseded by part number: 134836A1 |
| 42. | VA3089080700 | [2] | DIPSTICK | KOBOIL PRESSURE UNIT |
| 43. | VA0304931030 | [2] | GROUND STRAP | |
| 44. | VA3089005200 | [2] | SWITCH | KOBSTARTER |
| 45. | VA3096600071 | [2] | RELAY | KOBHEATER |
| 46. | VA3096690100 | [2] | HEATER INDICATOR | HEATER INDICATOR |
| 47. | VA3096690200 | [2] | RELAY | KOBSTATER SAFET |
