| . . | 24100X755F1 | [1] | BUCKET, CLAMSHELL, CONSISTS OF REF 2 TO 67 | |
| 2. | 2438U397F1 | [2] | CYLINDER | |
| 3. | 2412X189F1 | [1] | SHELL, CONSISTS OF REF 3-2 TO 3-8 | |
| 3-2. | 2412X189 | [1] | SHELL | |
| 3-3. | 2405T704 | [2] | BUSHING | BUSHING |
| 3-4. | 2405T702 | [2] | BUSHING | KOB |
| 3-5. | 2405T723 | [2] | BUSHING | |
| 3-6. | 2445R138D10 | [6] | SEAL,110mm ID x 130mm OD x 4mm Thk | KOBDust -- ID 110 x OD 130 x Th 4mm |
| 3-7. | 2445R138D6 | [4] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| 3-8. | 2416T5395 | [1] | COLLAR | |
| 4. | 2412X188F1 | [1] | SHELL, CONSISTS OF REF 4-2 TO 4-8 | |
| 4-2. | 2412X188 | [1] | SHELL | |
| 4-3. | 2405T704 | [2] | BUSHING | BUSHING |
| 4-4. | 2405T702 | [2] | BUSHING | KOB |
| 4-5. | 2405T723 | [2] | BUSHING | |
| 4-6. | 2445R138D10 | [6] | SEAL,110mm ID x 130mm OD x 4mm Thk | KOBDust -- ID 110 x OD 130 x Th 4mm |
| 4-7. | 2445R138D6 | [4] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| 4-8. | 2416T5395 | [1] | COLLAR | |
| 5. | 2436U408 | [1] | JOINT, SWIVEL | |
| 6. | 2416J441F1 | [1] | ARM, CONSISTS OF REF 6-2 TO 6-4 | |
| 6-2. | 2416J441 | [1] | ARM | |
| 6-3. | 2405T702 | [4] | BUSHING | KOB |
| 6-4. | 2445R138D10 | [8] | SEAL,110mm ID x 130mm OD x 4mm Thk | KOBDust -- ID 110 x OD 130 x Th 4mm |
| 7. | 2416J443F1 | [1] | BRACKET, CONSISTS OF REF 7-2 TO 7-3 | |
| 7-2. | 2416J443 | [1] | BRACKET | |
| 7-3. | 2405T704 | [2] | BUSHING | BUSHING |
| 9. | 2419P992 | [2] | PIN | |
| 10. | 2419P993 | [2] | PIN | |
| 11. | 2419P995 | [2] | PIN | |
| 12. | 2419P994 | [1] | PIN | |
| 13. | 2418T5498 | [8] | PLATE | |
| 14. | 2418T5500 | [4] | PLATE | |
| 15. | 2418T5503D1 | [1] | TUBF | |
| 16. | 2418T5503D2 | [1] | TUBE | |
| 17. | 2418T5504 | [2] | TUBE | |
| 18. | 2418T5505D1 | [1] | TUBE | |
| 19. | 2418T5505D2 | [1] | TUBE | |
| 20. | ZX56N12130 | [4] | HOSE | KOB |
| 21. | 2420T3204 | [1] | NUT | |
| 22. | 2416T5394 | [1] | WASHER | |
| 23. | 2405T724 | [1] | BUSHING | |
| 24. | 2417T307 | [2] | SPRING | |
| 25. | 2416T5392 | [1] | WASHER | |
| 27. | ZS13C10060 | [8] | SCREW | KOBM10x1.50x60mm Superseded by part number: ZS18C10060 |
| 28. | ZW22X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 29. | 44Z1D10 | [18] | FITTING | KOB |
| 30. | ZS11C16035 | [36] | SCREW,Hex, M16 x 35mm, Cl 4.8 | KOBM16x2.0x35mm |
| 31. | ZW22X16000 | [36] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 32. | ZS13C30090 | [14] | CAPSCREW | |
| 33. | ZN13C30024 | [14] | NUT | KOB |
| 34. | ZW22X30000 | [22] | WASHER, EXTERNAL | WASHER, EXTERNAL |
| 35. | ZW22K14000 | [16] | LOCK WASHER | KOBID 14.2 x OD 21.8 x Th 3.5mm |
| 36. | R20T0033D2 | [8] | CAPSCREW | |
| 37. | ZD12P02600 | [4] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 38. | R20T0033D1 | [8] | CAPSCREW | |
| 39. | R16P0035D5 | [4] | CLAMP | |
| 40. | ZS11C12075 | [8] | CAPSCREW M12x1.75x75mm | CAPSCREW M12x1.75x75mm |
| 41. | 2418P4405D1 | [1] | TUBE | |
| 42. | 2418P4405D2 | [1] | TUBE | |
| 43. | ZW22X12000 | [16] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 44. | 2406P1511F1 | [1] | LINK, CONSISTS OF REF 44-2 TO 44-4 | |
| 44-3. | 2405T702 | [2] | BUSHING | KOB |
| 44-4. | 2445R138D10 | [4] | SEAL,110mm ID x 130mm OD x 4mm Thk | KOBDust -- ID 110 x OD 130 x Th 4mm |
| 44-2. | 2406P1511 | [1] | LINK | |
| 45. | R16T0236 | [2] | SEAT, RUBBER | |
| 46. | 2419T1569D3 | [2] | PIN | |
| 47. | B16T0441 | [2] | PLATE | KOB |
| 48. | ZS11C12025 | [4] | CAPSCREW M12x1.75x25mm | CAPSCREW M12x1.75x25mm |
| 49. | ZD12P03800 | [4] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 50. | ZS61C10022 | [8] | CAPSCREW | |
| 51. | ZS11C12035 | [4] | SCREW,Hex, M12 x 35mm, Cl 4.8 | KOBM12x1.75x35mm Superseded by part number: ZS18C12035 |
| 52. | 2418T5497 | [2] | PLATE | |
| 53. | ZS13C30085 | [8] | SCREW | KOBCAPSCREW M30x3.50x85mm |
| 54. | 2420T2747D7 | [1] | SHIM,112mm ID x 180mm OD x 1.2mm Thk | KOBID 112 x OD 180 x Th 1.2mm |
| 55. | 2420T2747D8 | [1] | SHIM,112mm ID x 180mm OD x 1.6mm Thk | KOBID 112 x OD 180 x Th 1.6mm |
| 56. | 2420T2747D9 | [1] | SHIM,112mm ID x 180mm OD x 2.3mm Thk | KOBID 112 x OD 180 x Th 2.3mm |
| 57. | 2420T2747D10 | [1] | SHIM,112mm ID x 180mm OD x 3.2mm Thk | KOBID 112 x OD 180 x Th 3.2mm |
| 58. | B16T0442D1 | [1] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| 59. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| 60. | B16T0442D5 | [1] | SHIM,130mm OD x 72mm ID x 2.3mm Thk | KOBID 72 x OD 130 x Th 2.3mm |
| 61. | B16T0442D17 | [1] | SHIM,130mm OD x 72mm ID x 3.2mm Thk | KOBID 72 x OD 130 x Th 3.2mm |
| 62. | ZP15D10140 | [1] | COTTER PIN | KOB |
| 63. | ZS23C10060 | [8] | SCREW,Hex Socket Head, M10 x 60mm | KOBM10x1.50x60mm |
| 64. | ZW22K10000 | [8] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 65. | 2418T5535D1 | [8] | COLLAR | |
| 66. | 2418T5535D2 | [4] | COLLAR | |
| 67. | 44Z1D65 | [1] | FITTING, RELIEF | FITTING, RELIEF |
