神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (10-004) - BUCKET ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
899 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J2168F1 | [1] | BUCKET ASSY, CONSISTS OF REF 1 TO 5 | |
| 1. | 2412X190 | [1] | BUCKET | |
| 2. | B12K0014F1 | [6] | TOOTH, CONSISTS OF REF 2-1 TO 2-3 | |
| 2-1. | B12K0014E1 | [1] | POINT | POINT |
| 2-2. | B12K0014E2 | [1] | PIN, LOCKING | PIN, LOCKING |
| 2-3. | B12K0014E2 | [1] | PIN, LOCKING | PIN, LOCKING |
| 3. | B91K0017F1 | [1] | LINK GUIDE, CONSISTS OF REF 3-1 TO 3-3 | |
| 3-1. | B91K0017 | [1] | LINK GUIDE | |
| 3-2. | B05T0013 | [4] | BUSHING | BUSHING |
| 4. | B91N0052F1 | [2] | LINK, CONSISTS OF REF 4-1 TO 4-2 | |
| 4-1. | B91N0052 | [1] | LINK | |
| 4-2. | B05T0004 | [1] | BUSHING | BUSHING |
| 5. | 2444T1329D5 | [2] | PLUG | KOB Superseded by part number: ZF86P28000 |
