| 2. |
89837593
|
[1] |
CLAMP
|
ZED
Superseded by part number: 9837593
|
| 3. |
120104
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 4. |
80076344
|
[1] |
ELBOW
|
ZED
Superseded by part number: 76344
|
| 5. |
89827902
|
[2] |
CLAMP
|
ZED
Superseded by part number: 9827902
|
| 6. |
89837600
|
[2] |
PIN
|
ZED
Superseded by part number: 9837600
|
| 7. |
89837599
|
[1] |
PIN
|
ZED
Superseded by part number: 9837599
|
| 8. |
84042784
|
[1] |
CLAMP
|
ZED
|
| 9. |
89837609
|
[1] |
HYDRAULIC CYLINDER
|
ZED
(10,13,33) Superseded by part number: 9837609
|
| 10. |
9963849
|
[1] |
THREADED ROD
|
ZED
|
| 11. |
80380424
|
[1] |
LOCK NUT
|
ZED
M20 Superseded by part number: 380424
|
| 12. |
80395528
|
[1] |
SCREW
|
ZED
Superseded by part number: 395528
|
| 13. |
9963850
|
[1] |
THREADED BUSHING
|
ZED
|
| 14. |
89837590
|
[1] |
HOSE
|
ZED
9/16" Superseded by part number: 9837590
|
| 14. |
84078071
|
[1] |
FLEXIBLE HOSE,6.35mm ID x 2500mm L, SAE 100R1
|
ZED
M14
|
| 15. |
80128817
|
[1] |
HYD CONNECTOR
|
ZED
Superseded by part number: 128817
|
| 16. |
86544945
|
[1] |
QUICK MALE COUPLING
|
ZED
Superseded by part number: 87506450
|
| 17. |
89837597
|
[1] |
NUT
|
ZED
Superseded by part number: 9837597
|
| 18. |
89837598
|
[1] |
SCREW
|
ZED
Superseded by part number: 87015585
|
| 19. |
89837603
|
[1] |
TUBE
|
ZED
(34) Superseded by part number: 9837603
|
| 20. |
89837601
|
[1] |
BUSHING
|
ZED
Superseded by part number: 9837601
|
| 21. |
89837588
|
[1] |
SPRING
|
ZED
Superseded by part number: 9837588
|
| 22. |
80378243
|
[1] |
WASHER
|
ZED
Superseded by part number: 378243
|
| 23. |
89837596
|
[1] |
HOSE
|
ZED
Superseded by part number: 9837596
|
| 24. |
89837589
|
[1] |
ELBOW
|
ZED
Superseded by part number: 253449
|
| 25. |
89850792
|
[1] |
SHIELD
|
ZED
Superseded by part number: 9850792
|
| 26. |
80043442
|
[1] |
NUT,M8 x 1.25, Cl 8
|
ZED
Superseded by part number: 82034883
|
| 27. |
80322358
|
[1] |
LOCK WASHER
|
ZED
Superseded by part number: 322358
|
| 28. |
80043129
|
[1] |
SCREW
|
ZED
M8x40 Superseded by part number: 16044024
|
| 29. |
614-6016
|
[1] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86508568
|
| 30. |
80322357
|
[1] |
LOCK WASHER,Belleville, M6
|
ZED
6MM Superseded by part number: 322357
|
| 32. |
84042342
|
[1] |
DUST CAP
|
ZED
|
| 1. |
89706690
|
[4] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 33. |
84004361
|
[1] |
SEAL KIT
|
ZED
|
| 34. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Bushing
|
| 31. |
15896221
|
[1] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
