凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (07.08[01]) - DENSITY PRESSER SYSTEM, FRONT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
561 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84064526
|
[1] |
RESERVOIR, HYDRAULIC
|
ZED
(2,3,42) Superseded by part number: 84398983
|
| 2. |
84078485
|
[1] |
PLUG
|
ZED
|
| 3. |
84078484
|
[1] |
CAP
|
ZED
|
| 4. |
84074610
|
[1] |
HYD CONNECTOR
|
ZED
(5)
|
| 5. |
84032746
|
[1] |
O-RING,2.1mm Thk x 15.4mm ID, 90 Duro
|
ZED
|
| 6. |
80150014
|
[1] |
FERRULE
|
ZED
10MM Superseded by part number: 150014
|
| 7. |
86548975
|
[1] |
PIPE UNION NUT,M16 x 1.5
|
ZED
M10
|
| 8. |
80371539
|
[1] |
RIGID TUBE
|
ZED
D=10MM,L=2M Superseded by part number: 371539
|
| 9. |
84064606
|
[2] |
HYD CONNECTOR
|
ZED
|
| 10. |
84068686
|
[1] |
HYDRAULIC OIL FILTER
|
ZED
ASSEMBLY, (11)
|
| 11. |
84078520
|
[1] |
HYDRAULIC OIL FILTER
|
ZED
ELEMENT
|
| 12. |
84007700
|
[1] |
ELBOW
|
ZED
|
| 13. |
89813512
|
[1] |
HYD CONNECTOR
|
ZED
|
| 14. |
84043514
|
[1] |
HYD CONNECTOR
|
ZED
|
| 15. |
80335136
|
[1] |
FERRULE
|
ZED
8MM Superseded by part number: 335136
|
| 16. |
80335135
|
[1] |
NUT
|
ZED
M8 Superseded by part number: 335135
|
| 17. |
80371540
|
[1] |
RIGID TUBE
|
ZED
D=8MM,L=2M Superseded by part number: 371540
|
| 18. |
84069412
|
[1] |
ADVANCE VALVE
|
ZED
|
| 19. |
84068862
|
[1] |
HYD CONNECTOR
|
ZED
|
| 20. |
84064607
|
[1] |
HYD CONNECTOR
|
ZED
|
| 21. |
84069072
|
[1] |
HYD CONNECTOR
|
ZED
|
| 22. |
84100140
|
[1] |
HYD CONNECTOR
|
ZED
(23)
|
| 23. |
80165202
|
[1] |
O-RING
|
ZED
Superseded by part number: 70925921, 165202
|
| 24. |
84056783
|
[1] |
HYDRAULIC VALVE
|
ZED
|
| 25. |
89850318
|
[1] |
HYD CONNECTOR
|
ZED
Superseded by part number: 9850318
|
| 26. |
84064562
|
[1] |
HYD CONNECTOR
|
ZED
|
| 27. |
84041508
|
[1] |
HYD CONNECTOR
|
ZED
|
| 28. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Hose
|
| 29. |
80913888
|
[2] |
HOSE CLAMP
|
ZED
Superseded by part number: 913888
|
| 30. |
84064667
|
[1] |
HYD CONNECTOR
|
ZED
|
| 31. |
89837610
|
[1] |
MEASURING INSTRUMENT
|
ZED
Superseded by part number: 84801502
|
| 32. |
120104
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 33. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 35. |
80300510
|
[1] |
SCREW
|
ZED
M8x65 Superseded by part number: 300510
|
| 34. |
89706690
|
[1] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 36. |
80140041
|
[1] |
WASHER
|
ZED
9MM Superseded by part number: 87033737
|
| 37. |
86511816
|
[3] |
SCREW,Pan, M3 x 0.5 x 16mm, Cl 4.8
|
ZED
|
| 38. |
80412547
|
[3] |
LOCK WASHER
|
ZED
3MM Superseded by part number: 412547
|
| 39. |
86508812
|
[3] |
NUT,M3, Cl 8
|
ZED
Superseded by part number: 1175064
|
| 40. |
614-8016
|
[2] |
BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 16043224
|
| 41. |
84074545
|
[1] |
HYD CONNECTOR
|
ZED
(5)
|
| 42. |
84320893
|
[1] |
TUBE
|
ZED
|
