神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (10-009) - CATWALK ASSY, P/N 24100N1596F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
219 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N1596F1 | [1] | CATWALK CONSIST OF REF 1 TO 11 | |
| 1. | 2422P389 | [1] | CATWALK | |
| 2. | 2422P391 | [2] | CATWALK | |
| 3. | 2422P390 | [1] | CATWALK | |
| 4. | 2422P392 | [1] | CATWALK | |
| 5. | 2416T6616 | [8] | BLOCK TAPPED | |
| 6. | 2416T6617 | [3] | BLOCK TAPPED | |
| 7. | ZS11C16030 | [28] | CAPSCREW -- M16x2.0x30mm | |
| S. | ZW22X16000 | [28] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 9. | ZS11C12030 | [9] | CAP,Hex, M12 x 30mm, Cl 4.8 | KOBScrew -- M12x1.75x30mm Superseded by part number: ZM12C12030 |
| 10. | ZN11C12010 | [9] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 11. | ZW22X12000 | [9] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
