神钢零件查询(K935) - EXCAVATOR BTW L70106 - L70166, LU0067 (1/76-12/03) (10-008) - BASE ASSY, ELEVATED Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
285 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X813F1 | [1] | BASE ASSY, ELEVATED | |
| 1. | 2422J804 | [1] | | |
| 2. | 2416N1646 | [1] | | |
| 3. | 2416P4339 | [1] | | |
| 4. | 2414T1129 | [1] | | |
| 5. | 2418T5991 | [8] | | |
| 6. | 2419T2219 | [1] | | |
| 7. | 2416P4348 | [1] | | |
| 8. | 2422N458 | [1] | | |
| 9. | R06P0039D9F1 | [1] | FLEXIBLE CONTROL | KOB |
| 9-4. | R16T0042D1 | [1] | | |
| 9-5. | B1910175 | [1] | | |
| 9-6. | ZP15K01210 | [1] | LOCK PIN | KOB |
| 10. | R06P0039D10F1 | [1] | | |
| 10-4. | R16T0042D1 | [1] | | |
| 10-5. | B19T0175 | [1] | PIN | KOB |
| 10-6. | ZP15K01210 | [1] | LOCK PIN | KOB |
| 11. | 2420R349D100 | [18] | HOSE | KOB Superseded by part number: HX21E04100DX |
| 12. | 2420R350D100 | [4] | HOSE | HOSE |
| 13. | ZX15K08100 | [5] | TUBE | KOB |
| 14. | ZX15K06100 | [1] | TUBE, NYLON | TUBE, NYLON |
| 15. | ZX15K04100 | [1] | TUBE, NYLON | TUBE, NYLON |
| 16. | ZG21U04000 | [7] | SOCKET | KOB |
| 17. | ZH22F04000 | [1B] | HYD CONNECTOR | KOB |
| 18. | ZH22F06000 | [4] | CONNECTION | KOB |
| 19. | ZH21K04004 | [2] | HYD CONNECTOR | KOB |
| 20. | ZH21K06004 | [2] | CONNECTOR | CONNECTOR |
| 21. | ZH21K08004 | [10] | HYD CONNECTOR | KOB |
| 22. | ZS11C10020 | [10] | CAPSCREW M10x1.50x20mm | CAPSCREW M10x1.50x20mm |
| 23. | ZS11C16030 | [8] | Screw -- M16x2.0x30mm | |
| 21. | ZS12C20070 | [8] | SCREW,Hex, M20 x 70mm | KOBM20x2.50x70mm |
| 25. | ZW11X10000 | [10] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
| 26. | R16T0152D3 | [10] | WASHER | KOBFlat -- ID 21 x OD 37 x Th 4.5mm |
| 27. | ZW22X10000 | [10] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 28. | ZW22X16000 | [8] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 29. | ZS12C20050 | [2] | SCREW,Hex, M20 x 50mm | KOBM20x2.50x50mm Superseded by part number: ZS13C20050 |
| 30. | ZN11C20016 | [2] | NUT | KOBM20x2.50mm |
| 32. | 2418P3980D1 | [1] | | |
| 33. | 2418P3980D2 | [1] | | |
| 34. | R27T0016 | [1] | HINGE | KOB |
| 35. | R16T0201D3 | [4] | BLOCK TAPPED | |
| 36. | ZS11C12030 | [8] | CAP,Hex, M12 x 30mm, Cl 4.8 | KOBScrew -- M12x1.75x30mm Superseded by part number: ZM12C12030 |
| 37. | ZW22X12000 | [8] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 38. | 2429N313 | [1] | STEP | |
