纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-018[00]) - CONTROL ASSEMBLY, DOZER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
459 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY14M00006F1 | [1] | Dozer | |
| 1. | YY14M01014P1 | [1] | LEVER | KOB, Serial Range: YT06-18001-YT06-18229 Superseded by part number: YY14M01019P1 |
| 1. | YY14M01017P1 | [1] | LEVER | KOB, Serial Range: YT06-18230-YT06-18441 Superseded by part number: YY14M01019P1 |
| 1. | YY14M01019P1 | [1] | LEVER | KOB, Start Serial: YT06-18442 |
| 2. | PY20T01011P2 | [1] | LABEL | KOB |
| 3. | YY14M01015F1 | [1] | HANDLE GRIP | KOBAssy. Superseded by part number: YY14M01015F3 |
| 4. | 2420Z1232 | [1] | NUT | KOB |
| 5. | ZM73C10020 | [2] | BOLT,M10x20mm - Course Thread | KOBSems |
