纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-026[04]) - CONTROL LINES, MAIN (NIBBLER & BREAKER + DOZER + BOOM ARM SAFETY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
699 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT06H00059F1 | [1] | TUBE | KOBControl Lines, Main |
| 2. | ZH42X06000 | [1] | 45 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB |
| 3. | ZE72X06000 | [2] | PLUG | KOB |
| 4. | NSS | [1] | NOT SERVICED SEPARATELY | CONControl Lines, Main YT06H00108F1 |
| 5. | YT42H01128P1 | [1] | ELBOW | KOB |
| 6. | 2444Z3711 | [1] | HYD CONNECTOR | KOB |
| 7. | ZH22X04006 | [1] | HYD CONNECTOR | KOB |
