纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-026[05]) - CONTROL LINES, MAIN (NIBBLER & BREAKER + DOZER + BOOM ARM SAFETY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
184 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT06H00116F1 | [1] | TUBE | KOBControl Lines, Main |
| 2. | ZH32X04000 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB90 |
| 3. | ZH42X04000 | [1] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB45 |
| 4. | 2444Z2525 | [1] | HYD CONNECTOR | KOB |
| 5. | YT06H00124F1 | [1] | TUBE | KOBControl Lines, Main |
