纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-029[02]) - CONTROL LINES, VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
697 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2420R34D180 | [1] | | |
| 2. | 2420R349D200 | [1] | HOSE ASSY. | KOB |
| 3. | 2420R537D086 | [1] | HOSE,9.60mm ID x 860mm L | KOB Superseded by part number: 2420R537D090 |
| 4. | 2420R537D110 | [1] | HOSE ASSY.,9.60mm ID x 1100mm L | KOB Superseded by part number: HX21E06110DX |
| 5. | 2420R537D155 | [1] | HOSE,9.53mm ID x 1550mm L | KOB |
| 6. | YT42H01128P1 | [1] | ELBOW | KOB |
| 7. | 2444Z3279 | [1] | 90 ELBOW | KOB |
| 8. | ZE72X04000 | [2] | PLUG | KOB |
| 9. | ZH22X06000 | [1] | HYD CONNECTOR | KOB |
| 10. | ZH32X04000 | [2] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB90 |
| 11. | ZH32X06000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB90 |
| 12. | PH03H01066P1 | [1] | TEE | KOB |
| 13. | YN50V00020F1 | [1] | HYDRAULIC OIL FILTER | SMFilter, Inline |
| 14. | EW02E01015DD | [1] | CLIP | KOB |
| 15. | ZM73C10020 | [1] | BOLT,M10x20mm - Course Thread | KOB |
| 16. | ZS18C08080 | [2] | SCREW,Hex, M8 x 80mm | KOBCap |
| 17. | ZW16H08000 | [2] | WASHER | KOB |
| 18. | 2420R537D250 | [1] | HOSE ASSY.,9.60mm ID x 2500mm L | KOB |
| 19. | PU13E01010DE | [1] | TUBE | KOB |
| 20. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOB |
| 21. | YT35V00027F1 | [1] | SOLENOID VALVE | KOB |
| 22. | YT64H00105F1 | [1] | Valve | |
