纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-029[01]) - CONTROL LINES, VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
329 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT64H00102F1 | [1] | Valve | |
| 1. | YT64H00100F1 | [1] | Valve | |
| 2. | 2420R349D180 | [1] | HOSE,6.35mm ID x 1800mm L | KOB |
| 3. | 2420R349D200 | [1] | HOSE ASSY. | KOB |
| 4. | 2420R537D155 | [1] | HOSE,9.53mm ID x 1550mm L | KOB |
| 5. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| 6. | ZH42X04000 | [1] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB45 |
| 7. | EW02E01015D4 | [1] | CLIP | KOB |
| 8. | PY01P01043D8 | [5] | CABLE TIE,102mm L | KOB |
| 9. | YN13E01375P1 | [2] | CLIP,M8 x 8.20mm Shank | KOB |
| 10. | ZM73C10020 | [2] | BOLT,M10x20mm - Course Thread | KOBSems |
| 11. | 2420R537D250 | [1] | HOSE ASSY.,9.60mm ID x 2500mm L | KOB |
