| 1. |
89837857
|
[1] |
CLUTCH
|
ZED
, Serial Range: (12,36-47) Superseded by part number: 87364750
|
| 2. |
89837215
|
[2] |
FLANGE
|
ZED
Superseded by part number: 86620027
|
| 3. |
80552945
|
[1] |
BEARING ASSY
|
ZED
Superseded by part number: 412441
|
| 4. |
80120044
|
[1] |
BOLT
|
ZED
M12x30 Superseded by part number: 120044
|
| 5. |
86595275
|
[1] |
OFFSET LINK
|
ZED
Superseded by part number: 241-1716
|
| 6. |
89706685
|
[8] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 7. |
84074766
|
[1] |
SHAFT
|
ZED
|
| 7. |
84074764
|
[1] |
SHAFT
|
ZED
|
| 8. |
89706687
|
[3] |
SCREW
|
ZED
M12x30 Superseded by part number: 9706687
|
| 9. |
84074957
|
[1] |
DISC
|
ZED
|
| 10. |
80578189
|
[4] |
FLANGE
|
ZED
Superseded by part number: 86620026
|
| 11. |
80322360
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 322360
|
| 12. |
89837968
|
[1] |
SUPPORT
|
ZED
Superseded by part number: 9837968
|
| 13. |
80140046
|
[15] |
WASHER
|
ZED
12MM Superseded by part number: 140046
|
| 14. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 15. |
89837880
|
[1] |
GEAR
|
ZED
Superseded by part number: 9837880
|
| 16. |
80170026
|
[1] |
KEY
|
ZED
Superseded by part number: 170026
|
| 17. |
89837879
|
[1] |
CHAIN
|
ZED
(32) Superseded by part number: 9837879
|
| 18. |
80120049
|
[1] |
BOLT
|
ZED
M16x90 Superseded by part number: 120049
|
| 19. |
89837878
|
[1] |
SUPPORT
|
ZED
Superseded by part number: 9837878
|
| 20. |
80378246
|
[4] |
WASHER
|
ZED
16MM Superseded by part number: 378246
|
| 21. |
89837867
|
[3] |
DRIVEN SPROCKET
|
ZED
Superseded by part number: 87517107
|
| 22. |
80140048
|
[3] |
WASHER
|
ZED
16MM Superseded by part number: 140048
|
| 23. |
100020
|
[3] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 24. |
80120046
|
[1] |
BOLT
|
ZED
Superseded by part number: 87552612
|
| 25. |
89837964
|
[1] |
BUSHING
|
ZED
Superseded by part number: 9837964
|
| 26. |
89850764
|
[1] |
DISC
|
ZED
Superseded by part number: 9850764
|
| 27. |
89837966
|
[1] |
CHAIN
|
ZED
(32,5) Superseded by part number: 9837966
|
| 28. |
80333228
|
[1] |
KEY
|
ZED
Superseded by part number: 333228
|
| 29. |
84000091
|
[1] |
DRIVEN SPROCKET
|
ZED
|
| 30. |
80043139
|
[3] |
BOLT,M10 x 25mm
|
ZED
Superseded by part number: 11106231
|
| 31. |
80140045
|
[1] |
WASHER
|
ZED
Superseded by part number: 140045
|
| 32. |
80165590
|
[1] |
CONNECTING LINK
|
ZED
Superseded by part number: 241-1316
|
| 33. |
80338949
|
[7] |
CARRIAGE BOLT
|
ZED
M10x25 Superseded by part number: 338949
|
| 35. |
89837963
|
[1] |
SCREW
|
ZED
Superseded by part number: 9837963
|
| 36. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 37. |
84004304
|
[1] |
CLUTCH PLATE,76.2mm ID x 157.23mm OD x 9.53mm Thk
|
ZED
|
| 38. |
84004305
|
[1] |
CLUTCH PLATE
|
ZED
|
| 39. |
84004500
|
[1] |
CLUTCH DRIVING PLATE
|
ZED
|
| 40. |
84004306
|
[1] |
WASHER
|
ZED
|
| 41. |
84004501
|
[1] |
HOUSING
|
ZED
|
| 42. |
84004499
|
[1] |
HUB
|
ZED
|
| 43. |
84004498
|
[1] |
REPAIR KIT
|
ZED
(50)
|
| 44. |
84004298
|
[2] |
CIRCLIP
|
ZED
|
| 45. |
84004299
|
[2] |
RING
|
ZED
Superseded by part number: 87731760
|
| 46. |
84043419
|
[1] |
FLANGE
|
ZED
|
| 47. |
84026625
|
[2] |
DISC
|
ZED
|
| 48. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
SHAFT
|
| 51. |
89837842
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 9837842
|
