凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (13.02[01]) - PICK-UP, MAIN TRANSMISSION, LH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
447 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
89837215
|
[2] |
FLANGE
|
ZED
Superseded by part number: 86620027
|
| 2. |
80552945
|
[1] |
BEARING ASSY
|
ZED
Superseded by part number: 412441
|
| 3. |
89837866
|
[1] |
SUPPORT
|
ZED
Superseded by part number: 84372941
|
| 4. |
80578189
|
[2] |
FLANGE
|
ZED
Superseded by part number: 86620026
|
| 5. |
80322360
|
[1] |
BEARING ASSY
|
ZED
Superseded by part number: 322360
|
| 6. |
86511323
|
[2] |
WASHER,10.5mm ID x 20mm OD x 2mm Thk
|
NH
Superseded by part number: 14496621
|
| 7. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 8. |
80120049
|
[2] |
BOLT
|
ZED
M16x90 Superseded by part number: 120049
|
| 9. |
80378246
|
[4] |
WASHER
|
ZED
16MM Superseded by part number: 378246
|
| 10. |
80140048
|
[2] |
WASHER
|
ZED
16MM Superseded by part number: 140048
|
| 11. |
100020
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 12. |
80333228
|
[1] |
KEY
|
ZED
Superseded by part number: 333228
|
| 13. |
80140045
|
[1] |
WASHER
|
ZED
Superseded by part number: 140045
|
| 14. |
80043140
|
[4] |
BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
ZED
Superseded by part number: 43140
|
| 15. |
84007604
|
[2] |
BUSHING,17mm ID x 28mm OD x 29mm L
|
ZED
|
| 16. |
84000092
|
[1] |
DRIVEN SPROCKET
|
ZED
|
| 17. |
811-10030
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 18. |
89837969
|
[2] |
DRIVEN SPROCKET
|
ZED
Superseded by part number: 87517105
|
| 19. |
89850763
|
[1] |
RING
|
ZED
Superseded by part number: 9850763
|
| 20. |
89837965
|
[1] |
CHAIN
|
ZED
Superseded by part number: 9837965
|
| 21. |
80025816
|
[1] |
OFFSET LINK
|
ZED
Superseded by part number: 86595276
|
| 22. |
25194
|
[1] |
CONNECTING LINK
|
GI
Superseded by part number: 86537460
|
