凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (13.10[01]) - PACKER CLUTCH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
658 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84045305
|
[1] |
CLUTCH
|
ZED
, Serial Range: (2-14)
|
| 2. |
84045304
|
[1] |
DRIVEN SPROCKET
|
ZED
Superseded by part number: 84800490
|
| 3. |
84041823
|
[1] |
FLANGE
|
ZED
Superseded by part number: 84800488
|
| 4. |
80261798
|
[4] |
DISC
|
ZED
Superseded by part number: 261798
|
| 5. |
84041824
|
[3] |
DISC,97mm ID x 230mm OD x 3.5mm Thk
|
ZED
|
| 6. |
84041827
|
[1] |
CLUTCH DISC
|
ZED
|
| 7. |
84041833
|
[1] |
CIRCLIP
|
ZED
|
| 8. |
84041818
|
[1] |
GEAR
|
ZED
|
| 9. |
80140096
|
[1] |
WASHER
|
ZED
Superseded by part number: 9820493
|
| 10. |
80322270
|
[9] |
SPRING
|
ZED
Superseded by part number: 322270
|
| 11. |
84041820
|
[9] |
BUSHING,12.5mm ID x 17.2mm OD x 114.5mm L
|
ZED
|
| 12. |
80140042
|
[9] |
WASHER
|
ZED
Superseded by part number: 140042
|
| 13. |
80331168
|
[9] |
SCREW,M10 x 40mm
|
ZED
M10x140 Superseded by part number: 331168
|
| 14. |
84045306
|
[1] |
BUSHING,44.98mm ID x 50.02mm OD x 50mm L
|
ZED
|
