| 1. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 2. |
80140045
|
[1] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 3. |
84000485
|
[1] |
SUPPORT
|
ZED
|
| 3. |
89839102
|
[1] |
SUPPORT
|
ZED
Superseded by part number: 9839102
|
| 4. |
80338949
|
[1] |
CARRIAGE BOLT
|
ZED
M10x25 Superseded by part number: 338949
|
| 5. |
84074371
|
[1] |
FRAME
|
ZED
Superseded by part number: 84818762
|
| 5. |
84074372
|
[1] |
FRAME
|
ZED
Superseded by part number: 84818657
|
| 6. |
84000484
|
[1] |
PLATE
|
ZED
|
| 6. |
89839076
|
[1] |
PLATE
|
ZED
Superseded by part number: 9839076
|
| 7. |
84078468
|
[1] |
PLATE
|
ZED
|
| 7. |
84078464
|
[1] |
PLATE
|
ZED
|
| 8. |
86512443
|
[1] |
CARRIAGE BOLT,Sht Nk, M8 x 35mm, Cl 8.8, Full Thd
|
ZED
M8x35
|
| 9. |
89839096
|
[3] |
GUIDE
|
ZED
, Serial Range: -C275 Superseded by part number: 9839096
|
| 9. |
84429868
|
[2] |
GUIDE
|
ZED
|
| 10. |
84100500
|
[1] |
PLATE
|
ZED
|
| 12. |
80308761
|
[16] |
SCREW,M8 x 25mm
|
ZED
M8x25 Superseded by part number: 308761
|
| 13. |
80300423
|
[2] |
COTTER PIN
|
ZED
Superseded by part number: 300423
|
| 14. |
84004017
|
[1] |
ROD
|
ZED
|
| 14. |
89839098
|
[1] |
ROD
|
ZED
Superseded by part number: 9839098
|
| 15. |
89837806
|
[1] |
BEARING ASSY
|
ZED
Superseded by part number: 9837806
|
| 16. |
89839099
|
[1] |
GUIDE
|
ZED
Superseded by part number: 87380173
|
| 17. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 18. |
80309086
|
[2] |
SCREW,M12 x 60mm
|
ZED
M12x60 Superseded by part number: 309086
|
| 19. |
89706685
|
[6] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 20. |
43138
|
[42] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 21. |
80412152
|
[1] |
NUT
|
ZED
M6 Superseded by part number: 412152
|
| 22. |
811-8020
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 23. |
80043127
|
[1] |
SCREW,M8 x 25mm
|
ZED
M8x25 Superseded by part number: 43127
|
| 24. |
85005505
|
[1] |
GUIDE
|
ZED
|
| 24. |
85005504
|
[1] |
GUIDE
|
ZED
|
| 25. |
80300389
|
[6] |
BOLT,M12 x 35mm
|
ZED
M12x35 Superseded by part number: 628-12035
|
| 26. |
80140040
|
[1] |
WASHER
|
ZED
6MM Superseded by part number: 140040
|
| 27. |
80140046
|
[6] |
WASHER
|
ZED
12MM Superseded by part number: 140046
|
| 28. |
89839087
|
[1] |
RING
|
ZED
Superseded by part number: 9839087
|
| 29. |
89839092
|
[1] |
PLATE
|
ZED
Superseded by part number: 87380173
|
| 30. |
84005089
|
[2] |
STOP,M8 x 1.25 x 50mm, Rubber
|
ZED
|
| 31. |
84068989
|
[1] |
SUPPORT
|
ZED
|
| 31. |
84042612
|
[1] |
SUPPORT
|
ZED
|
| 32. |
84074219
|
[1] |
SUPPORT
|
ZED
|
| 32. |
84074226
|
[1] |
SUPPORT
|
ZED
|
| 33. |
86508583
|
[1] |
BOLT,Hex, M16 x 35mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 86529976
|
| 34. |
80394631
|
[1] |
WASHER
|
ZED
16MM Superseded by part number: 394631
|
| 35. |
80140048
|
[1] |
WASHER
|
ZED
16MM Superseded by part number: 140048
|
| 36. |
832-46416
|
[1] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 86000441
|
| 37. |
80043168
|
[6] |
BOLT
|
ZED
M16x40 Superseded by part number: 43168
|
| 38. |
80120090
|
[4] |
SCREW
|
ZED
M16x50 Superseded by part number: 120090
|
| 39. |
84073277
|
[1] |
PLATE
|
ZED
|
| 40. |
84074739
|
[1] |
SHAFT
|
ZED
Superseded by part number: 84818587
|
| 40. |
84074740
|
[1] |
SHAFT
|
ZED
Superseded by part number: 84818589
|
| 41. |
80378245
|
[4] |
WASHER
|
ZED
12MM Superseded by part number: 378245
|
| 11. |
89706690
|
[1] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 42. |
84607487
|
[2] |
STIFFENER
|
ZED
LH + RH
|
| 43. |
84607491
|
[2] |
PLATE
|
ZED
LH + RH
|
| 44. |
811-6016
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 16mm, Cl 8.8
|
CAS
M6x15 Superseded by part number: 86512439
|
| 45. |
84068687
|
[4] |
SCRAPER BLADE
|
ZED
|
| 45. |
89837273
|
[5] |
SCRAPER BLADE
|
ZED
Superseded by part number: 84800478
|
| 46. |
84607485
|
[3] |
PLATE
|
ZED
Middle
|
| 47. |
84607490
|
[3] |
PLATE
|
ZED
Middle
|
