纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR ASN YT06-18001 (01-050[03]) - CONTROLS, OPERATORS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
665 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY03M00276F1 | [1] | BOX | KOBAssy. |
| 2. | YN03M02165P1 | [1] | BRACKET | KOB |
| 3. | YN03M02207P1 | [1] | BOX | KOB |
| 4-1. | YN20M01799P1 | [1] | SPRING | KOBNot Illustrated - Strut in LH Control Box |
| 5. | YN03M02168P1 | [1] | LEVER ASSY & KNOB | KOB |
| 6. | YN03M02169P1 | [1] | COVER | KOB |
| 7. | YN03M02202P1 | [8] | SCREW,Hex Socket Head, M10 x 25mm | KOB Superseded by part number: ZS28C10025 |
| 8. | YN03M02204P1 | [10] | LOCK WASHER | KOB Superseded by part number: ZW26X10000 |
| 9. | YN03M02205P1 | [2] | SCREW | KOB Superseded by part number: ZS18C10025 |
| 10. | YN03M02203P1 | [1] | CAPTIVE WASHER SCREW,Hex Socket Head, M10 x 40mm | KOB Superseded by part number: ZS28C10040 |
