| 1. |
84433011
|
[1] |
WIRE HARNESS
|
ZED
|
| 2. |
84074079
|
[1] |
EXTENSION
|
ZED
|
| 2. |
84074080
|
[1] |
EXTENSION
|
ZED
|
| 3. |
84074077
|
[1] |
EXTENSION
|
ZED
|
| 3. |
84074078
|
[1] |
EXTENSION
|
ZED
|
| 4. |
84032866
|
[6] |
ROLLER,108mm OD x 743mm L
|
ZED
|
| 4. |
84032863
|
[6] |
ROLLER,108mm OD x 1127mm L
|
ZED
|
| 5. |
89839087
|
[10] |
RING
|
ZED
Superseded by part number: 9839087
|
| 6. |
89837933
|
[6] |
SPACER
|
ZED
Superseded by part number: 9837933
|
| 7. |
89837806
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 9837806
|
| 8. |
84074138
|
[2] |
CHAIN,1190mm L
|
ZED
|
| 9. |
89512549
|
[2] |
ROD
|
ZED
Superseded by part number: 9512549
|
| 10. |
80335169
|
[1] |
FERRULE
|
ZED
16MM Superseded by part number: 335169
|
| 11. |
84320651
|
[1] |
SUPPORT
|
ZED
|
| 12. |
84074054
|
[2] |
SUPPORT
|
ZED
|
| 13. |
84074051
|
[4] |
SUPPORT
|
ZED
|
| 14. |
84074052
|
[2] |
SUPPORT
|
ZED
|
| 15. |
84078292
|
[1] |
RETAINER COLLAR
|
ZED
|
| 16. |
84078290
|
[1] |
BRACKET
|
ZED
|
| 17. |
84078291
|
[1] |
BRACKET
|
ZED
|
| 18. |
80180043
|
[1] |
COTTER PIN
|
ZED
Superseded by part number: 180043
|
| 19. |
80309308
|
[2] |
SCREW
|
ZED
M12x120 Superseded by part number: 309308
|
| 20. |
80140046
|
[1] |
WASHER
|
ZED
12MM Superseded by part number: 140046
|
| 21. |
89706685
|
[1] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 22. |
80120046
|
[2] |
BOLT
|
ZED
M16x60 Superseded by part number: 87552612
|
| 23. |
80328754
|
[1] |
SCREW
|
ZED
M12x40 Superseded by part number: 328754
|
| 24. |
832-46416
|
[6] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 86000441
|
| 25. |
80320246
|
[2] |
BOLT
|
ZED
M16x70 Superseded by part number: 320246
|
| 26. |
100020
|
[12] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 27. |
80140048
|
[10] |
WASHER
|
ZED
16MM Superseded by part number: 140048
|
| 28. |
89838060
|
[6] |
SCREW
|
ZED
M16x40 Superseded by part number: 86595832
|
| 29. |
80120090
|
[2] |
SCREW
|
ZED
M16x50 Superseded by part number: 120090
|
| 30. |
80378246
|
[4] |
WASHER
|
ZED
16MM Superseded by part number: 378246
|
| 31. |
80381929
|
[1] |
PIN
|
ZED
Superseded by part number: 37428
|
| 32. |
80140104
|
[2] |
WASHER
|
ZED
Superseded by part number: 140104
|
| 33. |
120104
|
[14] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 34. |
80322358
|
[14] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 35. |
80120073
|
[1] |
SCREW,M10 x 80mm
|
ZED
M10x80 Superseded by part number: 129796A1
|
| 36. |
84429978
|
[1] |
SUPPORT
|
ZED
LH
|
| 36. |
84429980
|
[1] |
SUPPORT
|
ZED
RH
|
| 37. |
80043158
|
[1] |
SCREW,M12 x 80mm
|
ZED
M12x80 Superseded by part number: 43158
|
| 37. |
89706687
|
[8] |
SCREW
|
ZED
M12x30 Superseded by part number: 9706687
|
| 38. |
84037242
|
[1] |
BUSHING
|
ZED
|
| 39. |
84801333
|
[1] |
ROLLER,108mm OD x 749mm L
|
ZED
|
| 39. |
84801337
|
[1] |
ROLLER,108mm OD x 1127mm L
|
ZED
|
