凯斯零件查询(LBX331S) - BIG RECTANGULAR BALER (6/01-12/03) (15.03[01]) - KNOTTER, GEARBOX Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
476 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84078670
|
[1] |
GEARBOX
|
ZED
, Serial Range: (2-36) Superseded by part number: 47373915
|
| 2. |
80412256
|
[10] |
BOLT
|
ZED
|
| 3. |
84100761
|
[1] |
HOUSING
|
ZED
|
| 4. |
84100762
|
[1] |
GEAR
|
ZED
|
| 5. |
84100763
|
[2] |
BUSHING
|
ZED
|
| 6. |
84100764
|
[1] |
SEAL
|
ZED
|
| 7. |
80321951
|
[1] |
BEARING ASSY
|
ZED
Superseded by part number: 84265402
|
| 8. |
84100744
|
[1] |
PLUG,Sight Glass, 1/2" Gas
|
ZED
|
| 9. |
84100765
|
[1] |
SHIM
|
ZED
|
| 10. |
80370010
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 370010
|
| 11. |
322496550
|
[2] |
PLUG
|
ZED
|
| 12. |
84100766
|
[1] |
FLANGE
|
ZED
, Serial Range: (30-35)
|
| 13. |
84100767
|
[1] |
SEAL
|
ZED
|
| 14. |
84100741
|
[1] |
BALL BEARING,100mm ID x 150mm OD x 16mm W
|
ZED
|
| 15. |
84100768
|
[2] |
SHIM
|
ZED
Superseded by part number: 84100752
|
| 16. |
80161715
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 87282046
|
| 17. |
84100769
|
[1] |
SHIM
|
ZED
|
| 18. |
80370018
|
[1] |
SNAP RING
|
ZED
Superseded by part number: 370018
|
| 19. |
84100770
|
[1] |
SPACER
|
ZED
|
| 20. |
84100725
|
[1] |
SHIM,35.3mm ID x 48mm OD
|
ZED
|
| 21. |
80440441
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 87016944
|
| 22. |
84100771
|
[1] |
SEAL
|
ZED
Superseded by part number: 86539169
|
| 23. |
84100772
|
[1] |
GEAR
|
ZED
|
| 24. |
84100773
|
[1] |
CIRCLIP
|
ZED
|
| 25. |
322493800
|
[1] |
SET OF RINGS
|
ZED
Superseded by part number: 84320006
|
| 26. |
80120068
|
[1] |
SCREW
|
ZED
M10x40 Superseded by part number: 120068
|
| 27. |
84100774
|
[1] |
SPACER
|
ZED
|
| 28. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Identity plate
|
| 29. |
84100775
|
[1] |
BOLT
|
ZED
M10x20
|
| 30. |
80043154
|
[1] |
BOLT
|
ZED
M12x40 Superseded by part number: 86629541
|
| 31. |
84100755
|
[1] |
SHIM,0.3mm Thk
|
ZED
|
| 32. |
84100756
|
[1] |
SHIM,0.4mm Thk
|
ZED
|
| 33. |
84100757
|
[2] |
SHIM,0.5mm Thk
|
ZED
|
| 34. |
84100758
|
[1] |
INSERT
|
ZED
Superseded by part number: 87336142
|
| 36. |
84100760
|
[1] |
HOUSING
|
ZED
|
| 38. |
80043140
|
[1] |
BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
ZED
Superseded by part number: 43140
|
| 39. |
84429044
|
[1] |
SPRING WASHER
|
ZED
|
