| 1. |
84014041
|
[1] |
CAM
|
ZED
|
| 1. |
84075938
|
[1] |
CAM
|
ZED
|
| 2. |
89838862
|
[2] |
SPRING
|
ZED
Superseded by part number: 9838862
|
| 3. |
80140046
|
[8] |
WASHER
|
ZED
Superseded by part number: 140046
|
| 4. |
89838366
|
[1] |
ROLLER
|
ZED
Superseded by part number: 9838366
|
| 5. |
84014757
|
[1] |
BUSHING,12mm ID x 25mm OD x 14mm L
|
ZED
|
| 6. |
84400783
|
[1] |
ROLLER
|
ZED
|
| 7. |
84021161
|
[1] |
SET SCREW,M8 x 12mm
|
ZED
|
| 8. |
84100887
|
[1] |
ARM
|
ZED
|
| 9. |
80300488
|
[2] |
SCREW
|
ZED
Superseded by part number: 84814919
|
| 10. |
89838854
|
[1] |
KEY
|
ZED
Superseded by part number: 9838854
|
| 11. |
80062161
|
[1] |
LUBE NIPPLE
|
ZED
Superseded by part number: 62161
|
| 12. |
80412077
|
[1] |
KEY
|
ZED
Superseded by part number: 412077
|
| 13. |
89838843
|
[1] |
ARM
|
ZED
Superseded by part number: 84800481
|
| 14. |
89838844
|
[1] |
SHAFT
|
ZED
Superseded by part number: 9838844
|
| 15. |
84806601
|
[1] |
SPRING,Extension, 28.399mm OD x 108mm L
|
ZED
|
| 16. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 17. |
80300868
|
[1] |
ROLL PIN
|
ZED
6x36MM Superseded by part number: 300868
|
| 18. |
84058620
|
[1] |
PIN,20mm OD x 62mm L
|
ZED
|
| 20. |
80322358
|
[4] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 21. |
89837806
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 9837806
|
| 22. |
80308761
|
[3] |
SCREW,M8 x 25mm
|
ZED
Superseded by part number: 308761
|
| 23. |
84045180
|
[1] |
SHAFT
|
ZED
, Serial Range: (3,4,5,24-27)
|
| 23. |
84045452
|
[1] |
SHAFT
|
ZED
, Serial Range: (3,4,5,24-27)
|
| 24. |
89838237
|
[1] |
SCREW
|
ZED
, Serial Range: -C269 Superseded by part number: 9838237
|
| 24. |
84607927
|
[1] |
SCREW,#10 - 32 x 0.55",
|
ZED
, Start Serial: D270
|
| 25. |
89838236
|
[1] |
ROLLER
|
ZED
Superseded by part number: 47508395
|
| 26. |
89838235
|
[1] |
SCREW
|
ZED
Superseded by part number: 84607927
|
| 27. |
80399555
|
[1] |
NUT
|
ZED
Superseded by part number: 399555
|
| 28. |
86512443
|
[1] |
CARRIAGE BOLT,Sht Nk, M8 x 35mm, Cl 8.8, Full Thd
|
ZED
M8x35
|
| 19. |
89706690
|
[4] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
