| 1. |
80374895
|
[4] |
CARRIAGE BOLT
|
ZED
Superseded by part number: 374895
|
| 2. |
89706685
|
[4] |
NUT
|
ZED
Superseded by part number: 9706685
|
| 3. |
80327911
|
[5] |
CIRCLIP
|
ZED
Superseded by part number: 327911
|
| 4. |
80853175
|
[2] |
FLANGE
|
ZED
Superseded by part number: 76450
|
| 5. |
89838774
|
[1] |
BEARING ASSY
|
ZED
Superseded by part number: 9838774
|
| 6. |
89838819
|
[1] |
RING
|
ZED
Superseded by part number: 9838819
|
| 7. |
89838867
|
[12] |
SCREW
|
ZED
Superseded by part number: 9838867
|
| 8. |
89838865
|
[6] |
SPACER
|
ZED
Superseded by part number: 9838865
|
| 9. |
84019174
|
[1] |
CAM
|
ZED
|
| 10. |
80140045
|
[1] |
WASHER
|
ZED
Superseded by part number: 140045
|
| 11. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
321204
|
[3] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 13. |
80300662
|
[6] |
BOLT
|
ZED
Superseded by part number: 300662
|
| 14. |
84074915
|
[1] |
SUPPORT
|
ZED
(29)
|
| 15. |
811-10030
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 16. |
89838826
|
[1] |
PIN
|
ZED
Superseded by part number: 9838826
|
| 17. |
89838827
|
[1] |
COTTER PIN
|
ZED
Superseded by part number: 9838827
|
| 18. |
84004466
|
[2] |
SPACER
|
ZED
|
| 18. |
89838776
|
[3] |
SPACER
|
ZED
Superseded by part number: 9838776
|
| 19. |
89838753
|
[1] |
KEY
|
ZED
Superseded by part number: 9838753
|
| 20. |
84017722
|
[1] |
SHAFT
|
ZED
|
| 20. |
84017721
|
[1] |
SHAFT
|
ZED
|
| 21. |
89837743
|
[1] |
WASHER
|
ZED
Superseded by part number: 9837743
|
| 22. |
84014109
|
[6] |
SPRING
|
ZED
|
| 23. |
80543043
|
[6] |
WASHER
|
ZED
Superseded by part number: 543043
|
| 24. |
80100038
|
[6] |
NUT
|
ZED
Superseded by part number: 100038
|
| 25. |
89838757
|
[1] |
ARM
|
ZED
Superseded by part number: 84800480
|
| 26. |
89838773
|
[2] |
DISC
|
ZED
Superseded by part number: 84476390
|
| 27. |
89838755
|
[2] |
FLANGE
|
ZED
Superseded by part number: 84800479
|
| 28. |
89838835
|
[1] |
SHIM
|
ZED
THK.: 0.25MM Superseded by part number: 9838835
|
| 28. |
89838834
|
[1] |
SHIM
|
ZED
THK.: 0.8MM Superseded by part number: 9838834
|
| 29. |
89838824
|
[1] |
RING
|
ZED
Superseded by part number: 9838824
|
| 30. |
80412077
|
[1] |
KEY
|
ZED
Superseded by part number: 412077
|
| 31. |
80140046
|
[8] |
WASHER
|
ZED
Superseded by part number: 140046
|
| 32. |
84022935
|
[1] |
SET SCREW,Hex Soc, M8 x 8
|
ZED
|
